Tension Adjustment
- Belt tension is not manually adjustable, it is automatically adjusted by the drive belt auto-tensioner.
Scheme 7
- Remove the front RH wheel and tire. Refer to " «ADJUSTMENT»(ref-388047-S32116336402011022800000) ".
- Remove the front RH side cover.
- While securely holding the hexagonal part in pulley center of drive belt auto-tensioner, move in the direction of arrow (loosening direction of tensioner) using suitable tool. WARNING: Avoid placing hand in a location where pinching may occur if the holding tool accidentally comes off. CAUTION: Do not loosen the auto-tensioner pulley bolt. (Do not turn it counterclockwise. If turned counterclockwise, the complete auto-tensioner must be replaced as a unit, including pulley.)
- Insert a rod approximately 6 mm (0.24 in) in diameter through the rear of tensioner into retaining boss to lock tensioner pulley. Leave tensioner pulley arm locked until belt is installed again.
- Remove drive belt from crankshaft pulley and then remove it from the other pulleys.
