Engine Brake Adjustment
"ENGINE BRAKE LEVEL"
0 : Initial set value (Engine brake level control is activated)
OFF : Engine brake level control is deactivated.
| CAUTION | Mode of "+1" "0" "-1" "-2" "OFF" can be selected by touching "UP" or "DOWN" on CONSULT-III screen. However, do not select a mode other than "0" and "OFF". Selecting "+1" or "-1" or "-2" may cause irregular driveability. |
ADJUSTMENT AFTER INSTALLATION
After TCM is replaced, check programming as needed. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : SERVICE AFTER REPLACING TCM AND TRANSAXLE ASSEMBLY ".
Scheme 6
Scheme 7
Scheme 8
Scheme 9
- Disconnect the battery negative terminal. Refer to " «EXPLODED VIEW»(ref-388040-S03866086102011022800000) ".
- Move CVT shift selector to "N" position.
- Slide shift selector handle cover (3) downward. CAUTION: Be careful not to damage shift selector handle cover.
- Pull shift selector handle clip (2) out of CVT shift selector handle (1).
- Remove CVT shift selector handle and shift selector handle cover.
- Remove center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-388073-S20200356272011022800000) ".
- Move CVT shift selector to "P" position.
- Remove control cable (1) from CVT shift selector assembly. Refer to " «EXPLODED VIEW»(ref-388054-S26047513882011022800000) ".
- Remove CVT shift selector assembly (2). <--: Nut
- Disconnect CVT shift selector connector (A) using a suitable tool.
- Remove shift lock unit from CVT shift selector assembly.
Adjust the CVT positions after installing CVT shift selector. Refer to " INSPECTION AND ADJUSTMENT ".
Adjust the CVT positions after installing control cable. Refer to " INSPECTION AND ADJUSTMENT ".
Erase the CVT fluid deterioration data. Refer to " CONSULT-III FUNCTION (TRANSMISSION) ".
