OPERATION
Sunroof can be opened or closed and tilted up or down with sunroof switch.
RETAINED POWER OPERATION
When the ignition switch is turned to OFF position from ON or START position, power is supplied for 45 seconds
- to sunroof motor assembly terminal 5
- through BCM terminal 53.
When power is supplied, the sunroof can be operated.
The retained power operation is canceled when the driver or passenger side door is opened.
RAP signal period can be changed by CONSULT-II. Refer to CONSULT-II FUNCTION (BCM) .
CAN Communication System Description
Refer to CAN COMMUNICATION .
Scheme 1
Scheme 2
Scheme 3
CONSULT-II OPERATION
| CAUTION | If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be detected in self-diagnosis depending on control unit which carry out CAN communication. |
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
- With the ignition switch OFF, connect CONSULT-II and CONSULT-II CONVERTER to the data link connector, then turn ignition switch ON.
- Touch "START (NISSAN BASED VHCL)".
- Touch "BCM". If "BCM" is not indicated, go to «CONSULT-II DATA LINK CONNECTOR (DLC) CIRCUIT»(ref-233642-S33893762202006052600000) .
- Touch "RETAINED PWR".
- Select diagnosis mode. "DATA MONITOR", "ACTIVE TEST" and "WORK SUPPORT" are available.
