The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in SUPPLEMENTAL RESTRAINT SYSTEM (SRS) and SEAT BELTS .
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SUPPLEMENTAL RESTRAINT SYSTEM (SRS) . Do not use electrical test equipment on any circuit related to the SRS unless instructed to. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
Manual Operation
The driving position (seat position, steering wheel position and door mirror position) can be adjusted with the power seat switch, ADP steering switch or door mirror remote control switch.
Note. The door mirrors can be manually operated with the ignition switch turned to ACC or ON.
Scheme 1
Note. Disconnecting the battery erases the stored memory. After connecting the battery, insert the key into the ignition cylinder and turn the driver door switch ON (open) --> OFF (close) --> ON (open), the Entry/Exiting operation becomes possible. After exiting operation is carried out, entry operation can be operated.
Note. During automatic operation, if the ignition switch is turned ON --> START, the automatic operation is suspended. When the ignition switch returns to ON, it resumes.
SYSTEM DESCRIPTION
- The system automatically moves the driver seat and steering wheel to facilitate entry/exit to/from the vehicle. The automatic drive positioner control unit can also store the optimum driving positions (driver seat, steering wheel position and door mirror position) for 2 people. If the drivers change, one-touch operation allows changing to the other driving position.
- The settings (ON/OFF) of the automatic sliding seat (Entry/Exiting operation) at entry/exit can be changed as desired.
Fail-Safe Mode
When the ignition switch is in the ON position, if any of the parts (indicated in the following chart) move more than the specified amount within a period "T1" when no "ON" input is sent from any of the switches (indicated in the following chart), or an output from the automatic drive positioner is not produced, an output malfunction is sensed. Motor operation will be suspended automatically, and all automatic operations will be ineffective. (In this case, the motor will not operate manually).
| OPERATED PORTION | T1 |
|---|---|
| Seat sliding | Approx.2.5 sec. |
| Seat reclining | Same as above |
| Seat lifting (Front) | Same as above |
| Seat lifting (Rear) | Same as above |
| Seat wheel | Same as above |
FAIL-SAFE MODE
Memory Operation
Selecting the memorized position.
Scheme 2
Note. The driver's seat position and steering adjustment functions (see the following table) operate simultaneously in the order of priority.
| Priority | Function | Priority | Function |
|---|---|---|---|
| 1 | Seat sliding, (door mirror LH/RH) (1) | 4 | Seat lifter-FR |
| 2 | Steering wheel | 5 | Seat lifter-RR |
| 3 | Seat reclining | ||
| (1) *: In conjunction with sliding the seat, the door mirrors are positioned. | |||
| (1) | *: In conjunction with sliding the seat, the door mirrors are positioned. |
DRIVER'S SEAT POSITION AND STEERING ADJUSTMENT FUNCTIONS
Entry Operation
When the seat is in the exiting position, the following operation moves the seat and the steering wheel to the previous position before the exiting operation.
Scheme 3
Exiting Operation
At exit, the seat is automatically moved to the exiting position.
Scheme 4
- Seat: moves backward
- Steering wheel: raises.
Scheme 5
- Perform memory operation, exiting operation and entry operation by pressing key fob unlock button. NOTE: If Entry/Exiting operation is cancelled, perform memory operation only. If ignition switch turns ON in the middle of memory operation, do not perform exiting operation after memory operation. If ignition switch turns ON in the middle of exiting operation, shift into entry operation at that time.
