Lighting System: Removal & Installation Nissan Maxima A34

Exterior Lights 10 illustrations ~422 words

Bulb Replacement

Refer to DISASSEMBLY AND ASSEMBLY .

REMOVAL AND INSTALLATION

Refer to COMBINATION LAMP REMOVAL AND INSTALLATION .

REMOVAL AND INSTALLATION of Optical Sensor

  1. Remove instrument mask assembly. Refer to «REMOVAL AND INSTALLATION»(ref-233659-S22638579602006052600000) .
  2. While pressing pawl, remove the sensor unit from instrument mask.

Installation is in the reverse order of removal.

Scheme 108

Scheme 108

Scheme 109

Scheme 109: Component Parts and Harness Connector Location

Refer to COMBINATION LAMP REMOVAL AND INSTALLATION .

Scheme 110

Scheme 110: Component Parts and Harness Connector Location

Bulb Replacement (Front Turn Signal Lamp)

Refer to FRONT TURN SIGNAL LAMP .

Bulb Replacement (Rear Turn Signal Lamp)

Refer to BULB REPLACEMENT in REAR COMBINATION LAMP.

REMOVAL AND INSTALLATION of Front Turn Signal Lamp

Refer to COMBINATION LAMP REMOVAL AND INSTALLATION .

REMOVAL AND INSTALLATION of Rear Turn Signal Lamp

Refer to REMOVAL AND INSTALLATION in REAR COMBINATION LAMP.

Scheme 111

Scheme 111: Component Parts and Harness Connector Location

REMOVAL AND INSTALLATION of Cornering Lamp

  1. Disconnect connector.
  2. Remove bolts.
  3. Remove rear cover.
  4. Pull lamp forward out of fascia.

Installation is in the reverse order of removal.

Scheme 112

Scheme 112

Scheme 113

Scheme 113: REMOVAL AND INSTALLATION
  1. Remove steering column cover.
  2. While pressing tabs, pull lighting and turn signal switch toward driver door and disconnect from the base. Installation is in the reverse order of removal.

Scheme 114

Scheme 114: REMOVAL AND INSTALLATION
  1. Remove console finisher. Refer to «M/T Finisher»(ref-233659-S38109596082006052600000) (with M/T) or «A/T Finisher»(ref-233659-S16684313952006052600000) (with A/T).
  2. Remove screws from console finisher and remove the hazard switch. Installation is in the reverse order of removal.

For details, refer to REMOVAL AND INSTALLATION .

BULB REPLACEMENT, REMOVAL AND INSTALLATION

Refer to REMOVAL AND INSTALLATION .

Refer to BULB REPLACEMENT in REAR COMBINATION LAMP.

Refer to REMOVAL AND INSTALLATION in REAR COMBINATION LAMP.

Refer to BULB REPLACEMENT in REAR COMBINATION LAMP.

Refer to REMOVAL AND INSTALLATION in REAR COMBINATION LAMP.

Scheme 115

Scheme 115: Component Parts and Harness Connector Location

For bulb replacement, refer to BULB REPLACEMENT in HEADLAMP (FOR USA).

For bulb replacement, refer to BULB REPLACEMENT in REAR COMBINATION LAMP.

For bulb replacement, refer to BULB REPLACEMENT in REAR COMBINATION LAMP.

  1. Remove rear combination lamp. Refer to «REMOVAL AND INSTALLATION»(ref-233676-S38705052942006052600000) .
  2. Turn bulb socket counterclockwise and unlock it.
  3. Remove bulb.

Installation is in the reverse order of removal.

Scheme 116

Scheme 116: REMOVAL AND INSTALLATION
  1. Position trunk room trim aside. Refer to «REMOVAL AND INSTALLATION»(ref-233645-S31983045522006052600000) .
  2. Disconnect rear combination lamp connector.
  3. Remove rear combination lamp mounting nuts.
  4. Pull rear combination lamp to remove from the vehicle. Installation is in the reverse order of removal.

Scheme 117

Scheme 117: Component Parts and Harness Connector Location

REMOVAL

  1. Remove lower driver instrument panel. Refer to «Lower Driver Instrument Panel»(ref-233659-S05764257672006052600000) .
  2. Press tabs and carefully push illumination control switch out of lower driver instrument panel.

INSTALLATION

Installation is in the reverse order of removal.
