Starting & Charging System: Removal & Installation Nissan Maxima A34

Charging System 6 illustrations

INSTALLATION

Install in the reverse order of removal.

CAUTIONWhen installing, install positive battery terminal first. Battery fix frame mounting nut : 4.0 - 4.9 N.m (0.4 - 0.5 kg-m, 35 - 43 in-lb) Battery terminal nut : 3.0 - 3.9 N.m (0.3 - 0.4 kg-m, 26 - 34 in-lb)

To install, reverse the removal procedure.

Scheme 35

Scheme 35: INSTALLATION
Scheme 35: INSTALLATION

Scheme 36

Scheme 36: REMOVAL
Scheme 36: REMOVAL

Scheme 37

Scheme 37
Scheme 37
  1. Disconnect the negative battery terminal.
  2. Remove the starter insulator.
  3. Remove the harness bracket and harness protector from the starter engine room harness.
  4. Disconnect the starter harness connectors.
  5. Remove the two starter mounting bolts, using power tools.
  6. Remove the starter.

To install, reverse the removal procedure.

Scheme 38

Scheme 38: Disassembly and Assembly
Scheme 38: Disassembly and Assembly

Scheme 39

Scheme 39
Scheme 39

To install, reverse the removal procedure.

Scheme 40

Scheme 40: Disassembly and Assembly
Scheme 40: Disassembly and Assembly
