NETWORK CHECK Nissan Maxima A34

Audio Visual, Navigation & Telephone System 2 illustrations

NETWORK CHECK

Selecting NETWORK CHECK on self-diagnosis screen, display self-diagnostic results.

Scheme 305

Scheme 305: NETWORK CHECK
Scheme 305: NETWORK CHECK
Diagnosis itemContentsDTC return conditionReference at error
HVACOK/NGCommunication error between unified meter and A/C amp. and display unit.CAN COMMUNICATION LINE CHECK .
SWITCHOK/NGCommunication error between AV switch and display unit.AV COMMUNICATION LINE CHECK .
AUDIOOK/NGCommunication error between audio and display unit.AUDIO COMMUNICATION LINE CHECK .

DTC TROUBLESHOOTING CHART

Scheme 306

Scheme 306: PARTS CHECK
Scheme 306: PARTS CHECK
  1. Selecting PARTS CHECK on self-diagnosis screen, displays selection screen.
  2. Select DISPLAY, indicates DISPLAY DETAIL screen. Display diagnosis and setting can be performed.
  3. Select HVAC, indicates HVAC DETAIL screen. Auto air conditioner system self-diagnosis can be performed.
