Engine Controls - System & Component Testing - 4 Cyl & V6: Diagnosis Nissan Maxima A33

Testing & Diagnostics 7 illustrations ~203 words

EVAP System Leak Test

CAUTIONDO NOT apply more than.6 psi (.04 kg/cm 2 ) of pressure to EVAP system. DO NOT use compressed air.

Note. DO NOT start engine during testing procedure.

  1. Using CONSULT-II Attach EVAP service port adapter securely to EVAP service port. Attach pressure pump and hose. Turn ignition on. Using CONSULT-II in WORK SUPPORT MODE select EVAP SYSTEM CLOSE. Touch START. A bar graph should appear, using pressure pump apply pressure until pressure indicator reaches middle of graph. Remove EVAP service port adapter along with pump. Locate leak using Leak Detector (J41416).
  2. Without CONSULT-II Connect suitable pressure pump with gauge to EVAP service port. See «VACUUM DIAGRAMS»(ref-135815) article for location. Using jumper wires, apply battery voltage to EVAP Canister Vent Control Valve (EVAP-CVCV) and vacuum cut valve by-pass valve. (Scheme 76)- (Scheme 82). Apply.2-.4 psi (.01-.03 kg/cm 2 ) of pressure to EVAP service port. Remove pressure pump from EVAP service port. Using Leak Detector (J41416), locate EVAP system leak.

Scheme 76

Scheme 76

Scheme 77

Scheme 77

Scheme 78

Scheme 78

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82

IDLE AIR CONTROL VALVE-FAST IDLE CONTROL DEVICE SYSTEM TEST

Note. Altima, I35, Maxima, Pathfinder, QX4 and Sentra are not equipped with idle air control valve-fast idle control device.
