Engine Controls - Specifications 3.0: Other Nissan Maxima A32

Specifications 1 illustration ~172 words

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed (on dual plugs, remove exhaust side only) and throttle wide open.

VALVE CLEARANCE

Note. All engines, except KA24DE, GA16DE and VQ30DE, are equipped with hydraulic lifters. Adjustments are not required.

ApplicationHot - In. (mm)
Intake.010-.013, (.26-.34)
Exhaust.011-.015, (.29-.37)

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

ApplicationPrimarySecondary
Maxima.8Infinite

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH TENSION WIRE RESISTANCE

Application (1)Ohms
Plug Wires30,000 Maximum
Coil Wire7000 Maximum
(1) Not applicable to Distributorless Ignition Systems (DIS).
(1)Not applicable to Distributorless Ignition Systems (DIS).

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNGK
MaximaPFR5G-11

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
Maxima.039-.043 (1.00-1.10)14-22 (20-29)

SPARK PLUG SPECIFICATIONS

Firing Order. Scheme 1

Scheme 1: Firing Order

IGNITION TIMING

Note. For ignition timing adjustment procedures, see ADJUSTMENTS article.

ApplicationMan. Trans.(1) Auto. Trans.
Maxima13-17 @ 575-67513-17 @ 650-750
(1) Automatic transmission/transaxle in Neutral.
(1)Automatic transmission/transaxle in Neutral.

IGNITION TIMING (Degrees BTDC @ RPM)

FUEL PUMP

ApplicationAt Idle W/O Vacuum psi (kg/cm 2 )At Idle W/Vacuum psi (kg/cm 2 )
Maxima43 (3.0)34 (2.4)

REGULATED FUEL PRESSURE

FUEL INJECTOR RESISTANCE

Fuel injectors used by all models should have same resistance value of 10-14 ohms.

IDLE SPEED & MIXTURE

Note. For idle speed and mixture adjustment procedures, see ADJUSTMENTS article.

Application(1) Idle RPM(2) Idle RPM(3) CO Level
A/T(4) 575-675(4) 600-70010%
M/T575-675525-62510%
(1) With Auxiliary Air Control (AAC) valve connected. (2) With Auxiliary Air Control (AAC) valve disconnected. (3) Measured in Self-Diagnostic Mode II. (4) Automatic transmission/transaxle in Neutral.
(1)With Auxiliary Air Control (AAC) valve connected.
(2)With Auxiliary Air Control (AAC) valve disconnected.
(3)Measured in Self-Diagnostic Mode II.
(4)Automatic transmission/transaxle in Neutral.

IDLE SPEED & CO LEVEL

THROTTLE POSITION SENSOR

For adjustment specifications, see appropriate adjustment procedures in ADJUSTMENTS article.

THROTTLE POSITION SWITCH

ApplicationTerminals(1) Ohms
Closed Throttle2 & 3Continuity
Open Throttle2 & 3No Continuity
(1) With ignition off.
(1)With ignition off.

CLOSED THROTTLE POSITION SWITCH SPECIFICATIONS

ApplicationTerminals(1) Ohms
Closed Throttle1 & 2Continuity
Open Throttle1 & 2No Continuity
(1) With ignition off.
(1)With ignition off.

WOT POSITION SWITCH SPECIFICATIONS
