Generator Specifications
| Application | Specification | ||
|---|---|---|---|
| Generator Model | LR1100-711, HITACHI | LR1110-709, HITACHI | |
| Nominal Rating | 12 Volts, 100 Amps | 12 Volts, 110 Amps | |
| Ground Polarity | Negative | ||
| Minimum RPM Under No Load (With 13.5 Volts Applied) | Less Than 1,000 RPM | ||
| Hot Output Current (With 13.5 Volts Applied) | |||
| At 1300 RPM | 35 Amps | 35 Amps | |
| At 2500 RPM | 83 Amps | 85 Amps | |
| At 5000 RPM | 95 Amps | 110 Amps | |
| Regulated Output Voltage | 14.1-14.7 Volts | ||
| Minimum Brush Length | .236 in. (6.00 mm) | ||
| Brush Spring Pressure | 3.60-88.2 ozs. (1.000-2.452 N) | ||
| Slip Ring Minimum OuterDiameter | 1.024 in. (26.00 mm) | ||
| Rotor (Field Coil) Resistance | 2.31 Ohms | ||
GENERATOR SPECIFICATIONS
Torque Specifications
| Application | Ft. Lbs (N.m) | |
|---|---|---|
| Generator Lower Mounting Bolt | 32-38 (44-52) | |
| Generator Upper Mounting Bolt | 18-23 (24-31) | |
| Generator Pulley Nut | 36-47 (49-64) | |
| INCH Lbs. (N.m) | ||
| Terminal Connector Nut | 71-97 (8-11) | |
TORQUE SPECIFICATIONS
