Washer Nozzle Spray Position Adjustment
Adjust spray positions to match the positions shown in the figure below.
Scheme 7
| Unit: mm (in) | |||||
|---|---|---|---|---|---|
| Spray position | H | L | X | Y | S |
| A | 244 (9.61) | 350 (13.78) | 80 (3.15) | 238 (9.37) | 78 (3.07) |
| B | 284 (11.18) | 93 (3.66) | 80 (3.15) | 257 (10.12) | 89 (3.50) |
| C | 258 (10.16) | 70.5 (2.78) | 80 (3.15) | 255 (10.04) | 82 (3.23) |
| D | 309 (12.17) | 234 (9.21) | 80 (3.15) | 312 (12.28) | 95 (3.74) |
| E | 235 (9.25) | 413 (16.26) | 80 (3.15) | 295 (11.61) | 90 (3.54) |
Insert a needle or similar object (A) into the spray opening (1) and move up/down and left/right to adjust the spray position.
Note. If wax or dust gets into the nozzle, remove wax or dust with a needle or small pin.
Scheme 8
Scheme 9
Scheme 10
- Operate front wiper to move it to the auto stop position.
- Open the hood.
- Disengage front wiper arm cap (1) fixing pawls with a remover tool (A), and then remove front wiper arm cap from the wiper arm (2).
- Remove front wiper arm mounting nuts.
- Raise front wiper arm, and then remove front wiper arm from the vehicle.
Scheme 11
- Clean wiper arm mount as shown in the figure below to prevent nuts from being loosened.
- Operate front wiper motor to move the front wiper to the auto stop position.
- Adjust front wiper blade position. Refer to " «ADJUSTMENT»(ref-621435-S02427374112014061000000) ".
- Install front wiper arm by tightening the mounting nuts.
- Inject the washer fluid.
- Operate front wiper to move it to the auto stop position.
- Check that the front wiper blades stop at the specified position.
- Install front wiper arm caps.
WIPER BLADE POSITION ADJUSTMENT
Clearance between the end of cowl top cover/front fender protector and the top of wiper blade center
Scheme 12
Standard clearance
R: 37.7 ± 7.5 mm (1.484 ± 0.295 in)
L: 46.8 ± 7.5 mm (1.843 ± 0.295 in)
Scheme 13
REAR WIPER BLADE POSITION ADJUSTMENT
Set the wiper blade top on the defrosting wire (A) (clearance between the end of back door glass and the top of wiper blade center).
Standard clearance
Scheme 14
Scheme 15
Adjust spray positions to match the positions shown in the figure below.
Scheme 16
| Unit: mm (in) | ||
|---|---|---|
| L: Length | H: Height | Ø: Spray area |
| 122.8 (4.83) | 32.8 (1.29) | 30 (1.18) |
Insert a needle or similar object (A) into the spray opening (1) and move up/down and left/right to adjust the spray position.
Note. If wax or dust gets into the spray opening of rear washer nozzle (2), remove wax or dust with a needle or small pin.
