Starting System: Diagnosis Nissan Juke I facelift

Starter 4 illustrations ~665 words

Diagnosis Procedure

CAUTIONPerform diagnosis under the condition that engine cannot start by the following procedure. Remove fuel pump fuse. Crank or start the engine (where possible) until the fuel pressure is released.
  1. CHECK FUSIBLE LINK Check that the following fusible link is not blown. Terminal No. Signal name Fusible link No. 2 Battery power supply A (250A) Is the fusible link blown? YES: Replace the blown fusible link after repairing the affected circuit if a fusible link is blown. NO: GO TO 2.
  2. CHECK "B" TERMINAL CIRCUIT Turn ignition switch OFF. Check that starter motor "B" terminal connection is clean and tight. Check voltage between starter motor "B" terminal and ground. Terminals Voltage (Approx.) (+) (-) Starter motor "B" terminal Terminal E59 2 Ground Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Check harness between battery and starter motor for open circuit.
  3. CHECK BATTERY CABLE CONNECTION STATUS (VOLTAGE DROP TEST) Shift selector lever to "P" or "N" position. (CVT models) Keep depressing clutch pedal fully. (M/T models) Check voltage between battery positive terminal and starter motor "B" terminal. Terminals Condition Voltage (Approx.) (+) (-) Starter motor "B" terminal Terminal Battery positive terminal E59 2 When the ignition switch is in START position Less than 0.5 V Is the inspection result normal? YES: GO TO 4. NO: Check harness between the battery and the starter motor for poor continuity.
  4. CHECK GROUND CIRCUIT STATUS (VOLTAGE DROP TEST) Shift selector lever to "P" or "N" position. (CVT models) Keep depressing clutch pedal fully. (M/T models) Check voltage between starter motor case and battery negative terminal. Terminals Condition Voltage (Approx.) (+) (-) Starter motor case Battery negative terminal When the ignition switch is in START position Less than 0.2 V Is the inspection result normal? YES: "B" terminal circuit is OK. Further inspection is necessary. Refer to " «WORK FLOW (WITH GR8-1200 NI)»(ref-621395-S37232099382014061000000) " or " «WORK FLOW (WITHOUT GR8-1200 NI)»(ref-621395-S13931945952014061000000) ". NO: Check the starter motor case and ground for poor continuity.
CAUTIONPerform diagnosis under the condition that engine cannot start by the following procedure. Remove fuel pump fuse. Crank or start the engine (where possible) until the fuel pressure is released.
  1. CHECK "S" TERMINAL CIRCUIT Turn ignition switch OFF. Disconnect starter motor connector. Shift selector lever to "P" or "N" position. (CVT models) Keep depressing clutch pedal fully. (M/T models) Check voltage between starter motor harness connector and ground. Terminals Condition Voltage (Approx.) (+) (-) Starter motor harness connector Terminal F10 1 Ground When the ignition switch is in START position Battery voltage Is the inspection result normal? YES: "S" terminal circuit is OK. Further inspection is necessary. Refer to " «WORK FLOW (WITH GR8-1200 NI)»(ref-621395-S37232099382014061000000) " or " «WORK FLOW (WITHOUT GR8-1200 NI)»(ref-621395-S13931945952014061000000) ". NO: GO TO 2.
  2. CHECK HARNESS CONTINUITY (OPEN CIRCUIT) Disconnect IPDM E/R connector. Check continuity between starter motor harness connector and IPDM E/R harness connector. Starter motor harness connector IPDM E/R harness connector Continuity Connector No. Terminal No. Connector No. Terminal No. F10 1 E10 3 Existed Is the inspection result normal? YES: Further inspection is necessary. Refer to " «WORK FLOW (WITH GR8-1200 NI)»(ref-621395-S37232099382014061000000) " or " «WORK FLOW (WITHOUT GR8-1200 NI)»(ref-621395-S13931945952014061000000) ". NO: Repair the harness.

Symptom Table

SymptomReference
No normal crankingRefer to " WORK FLOW (WITH GR8-1200 NI) " or " WORK FLOW (WITHOUT GR8-1200 NI) ".
Starter motor does not rotate

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2: DISASSEMBLY
Scheme 2: DISASSEMBLY

Note. Apply high-temperature grease to lubricate the bearing, gears and frictional surface when assembling the starter.

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect the battery cable from the negative terminal. Refer to " «REMOVAL AND INSTALLATION»(ref-621371-S21917216672014061000000) ".
  2. Drain engine coolant from radiator. Refer to " «DRAINING»(ref-621380-S29109417532014061000000) ".
  3. Remove charge air cooler. Refer to " «REMOVAL AND INSTALLATION»(ref-621377-S27836533192014061000000) ".
  4. Remove CVT water hose on thermostat housing side (CVT models). Refer to " «EXPLODED VIEW»(ref-621380-S04451570432014061000000) ".
  5. Remove radiator hose (lower) on water inlet side. Refer to " «REMOVAL AND INSTALLATION»(ref-621380-S14412088322014061000000) ".
  6. Move CVT water hose A and radiator hose (lower) to a location where they do not inhibit work.
  7. Open "B" terminal cover, in the direction indicated by an arrow, as shown in the figure below.
  8. Remove "B" terminal nut and "B" terminal harness.
  9. Remove "S" terminal nut and "S" terminal harness.
  10. Disconnect harness connector (1) from crankshaft position sensor.
  11. Remove harness fixing clip (A) from oil pan (upper), and then move harness (2) to a location where they do not inhibit work.
  12. Remove starter motor mounting bolts.
  13. Remove starter motor forward from the vehicle.
