Brake System: Adjustments Nissan Juke I facelift

Mechanical - Hydraulic 8 illustrations ~513 words

ADJUSTMENT

Burnish contact surfaces between disc rotor and brake pads according to the following procedure after refinishing or replacing brake pads, or if a soft pedal occurs at very low mileage.

CAUTIONBe careful of vehicle speed because the brake does not operate firmly/securely until pads and disc rotor are securely fitted. Only perform this procedure under safe road and traffic conditions. Use extreme caution.
  1. Drive vehicle on straight, flat road.
  2. Depress brake pedal with the power to stop vehicle within 3 to 5 seconds until the vehicle stops.
  3. Drive without depressing brake for a few minutes to cool the brake.
  4. Repeat steps 1 to 3 until pad and disc rotor are securely fitted.

Burnish contact surfaces between disc rotors and brake pads according to the following procedure after refinishing or replacing disc rotor, or if a soft pedal occurs at very low mileage.

CAUTIONBe careful of vehicle speed because the brake does not operate firmly/securely until pad and disc rotor are securely fitted. Only perform this procedure under safe road and traffic conditions. Use extreme caution.
  1. Drive vehicle on straight, flat road.
  2. Depress brake pedal with the power to stop vehicle within 3 to 5 seconds until the vehicle stops.
  3. Drive without depressing brake for a few minutes to cool the brake.
  4. Repeat steps 1 to 3 until pad and disc rotor are securely fitted.

Burnish contact surfaces between disc rotor and brake pads according to the following procedure after refinishing or replacing brake pads, or if a soft pedal occurs at very low mileage.

CAUTIONBe careful of vehicle speed because the brake does not operate firmly/securely until pads and disc rotor are securely fitted. Only perform this procedure under safe road and traffic conditions. Use extreme caution.
  1. Drive vehicle on straight, flat road.
  2. Depress brake pedal with the power to stop vehicle within 3 to 5 seconds until the vehicle stops.
  3. Drive without depressing brake for a few minutes to cool the brake.
  4. Repeat steps 1 to 3 until pad and disc rotor are securely fitted.

Burnish contact surfaces between disc rotors and brake pads according to the following procedure after refinishing or replacing disc rotor, or if a soft pedal occurs at very low mileage.

CAUTIONBe careful of vehicle speed because the brake does not operate firmly/securely until pad and disc rotor are securely fitted. Only perform this procedure under safe road and traffic conditions. Use extreme caution.
  1. Drive vehicle on straight, flat road.
  2. Depress brake pedal with the power to stop vehicle within 3 to 5 seconds until the vehicle stops.
  3. Drive without depressing brake for a few minutes to cool the brake.
  4. Repeat steps 1 to 3 until pad and disc rotor are securely fitted.

Scheme 1

Scheme 1: Exploded View
Scheme 1: Exploded View

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3
  1. Remove instrument lower panel. Refer to " «REMOVAL AND INSTALLATION»(ref-621414-S19239322442014061000000) ".
  2. Disconnect the stop lamp switch and the brake pedal position switch harness connectors.
  3. Rotate the stop lamp switch and the brake pedal position switch (1) counter clockwise to remove.
  4. Disconnect the accelerator pedal harness connector and harness clip.
  5. Remove snap pin (1) and clevis pin (2) from clevis (3) of brake booster.
  6. Remove the steering member stay (1).
  7. Remove the brake pedal assembly. CAUTION: Hold the brake booster and master cylinder assembly so as not to drop out or contact them other parts.
  8. Remove accelerator pedal from brake pedal assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-621413-S25399546852014061000000) ".
  9. Perform inspection after removal. Refer to " «INSPECTION AND ADJUSTMENT»(ref-621383-S28371240752014061000000) ".

Scheme 4

Scheme 4
Scheme 4

ADJUSTMENT AFTER INSTALLATION

  1. Adjust each item of brake pedal after installing the brake pedal assembly to the vehicle. Refer to " «INSPECTION AND ADJUSTMENT»(ref-621383-S14994869302014061000000) ".
  2. Perform the release position learning of the accelerator pedal. Refer to " «WORK PROCEDURE»(ref-621378-S30187081762014061000000) ".

Scheme 5

Scheme 5: FRONT: Exploded View
Scheme 5: FRONT: Exploded View

Scheme 6

Scheme 6: 2WD
Scheme 6: 2WD

Scheme 7

Scheme 7: AWD
Scheme 7: AWD

Perform the brake pedal adjustment after installing the brake pedal assembly. Refer to " INSPECTION AND ADJUSTMENT ".

Scheme 8

Scheme 8: Exploded View
Scheme 8: Exploded View
