APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
| Diagnosis mode | Function Description |
|---|
| Work Support | Changes the setting for each system function. |
| Self Diagnostic Result | Displays the diagnosis results judged by BCM. |
| CAN Diag Support Monitor | Monitors the reception status of CAN communication viewed from BCM. |
| Data Monitor | The BCM input/output signals are displayed. |
| Active Test | The signals used to activate each device are forcibly supplied from BCM. |
| ECU Identification | The BCM part number is displayed. |
| Configuration | Read and save the vehicle specification. Write the vehicle specification when replacing BCM. |
SYSTEM APPLICATION
BCM can perform the following functions for each system.
Note. It can perform the diagnosis modes except the following for all sub system selection items.
| X: Applicable item |
|---|
| System | Sub system selection item | Diagnosis mode |
| Work Support | Data Monitor | Active Test |
| Door lock | DOOR LOCK | X | X | X |
| Rear window defogger | REAR DEFOGGER | | X | X |
| Warning chime | BUZZER | | X | X |
| Interior room lamp timer | INT LAMP | X | X | X |
| Exterior lamp | HEAD LAMP | X | X | X |
| Wiper and washer | WIPER | X | X | X |
| Turn signal and hazard warning lamps | FLASHER | X | X | X |
| Air conditioning system | AIR CONDITONER | | X | X (1) |
| Intelligent Key system Engine start system | INTELLIGENT KEY | X | X | X |
| Combination switch | COMB SW | | X | |
| Body control system | BCM | X | | |
| NVIS - NATS | IMMU | X | X | X |
| Interior room lamp battery saver | BATTERY SAVER | X | X | X |
| Back door open | TRUNK | | X | |
| Theft warning alarm | THEFT ALM | X | X | X |
| RAP | RETAINED PWR | | X | |
| Signal buffer system | SIGNAL BUFFER | | X | X |
| TPMS | AIR PRESSURE MONITOR | X | X | X |
| NOTE: (1) For models with automatic A/C, this diagnosis mode is not used. |
| NOTE |
|---|
| (1) For models with automatic A/C, this diagnosis mode is not used. |
| (1) | For models with automatic A/C, this diagnosis mode is not used. |
CONSULT performs the following functions via CAN communication with BCM.
| Diagnosis mode | Function Description |
|---|
| Work Support | Changes the setting for each system function. |
| Self Diagnostic Result | Displays the diagnosis results judged by BCM. |
| CAN Diag Support Monitor | Monitors the reception status of CAN communication viewed from BCM. |
| Data Monitor | The BCM input/output signals are displayed. |
| Active Test | The signals used to activate each device are forcibly supplied from BCM. |
| ECU Identification | The BCM part number is displayed. |
| Configuration | Read and save the vehicle specification. Write the vehicle specification when replacing BCM. |
BCM can perform the following functions for each system.
Note. It can perform the diagnosis modes except the following for all sub system selection items.
| X: Applicable item |
|---|
| System | Sub system selection item | Diagnosis mode |
| Work Support | Data Monitor | Active Test |
| Door lock | DOOR LOCK | X | X | X |
| Rear window defogger | REAR DEFOGGER | | X | X |
| Warning chime | BUZZER | | X | X |
| Interior room lamp control | INT LAMP | X | X | X |
| Remote keyless entry system | MULTI REMOTE ENT | X | X | X |
| Exterior lamp | HEAD LAMP | X | X | X |
| Wiper and washer | WIPER | X | X | X |
| Turn signal and hazard warning lamps | FLASHER | | X | X |
| Air conditioning system | AIR CONDITONER | | X | X |
| Combination switch | COMB SW | | X | |
| Body control system | BCM | X | | |
| NATS | IMMU | X | | X |
| Interior room lamp battery saver | BATTERY SAVER | X | X | X |
| Back door open | TRUNK | | X | |
| Theft warning alarm | THEFT ALM | X | X | X |
| RAP system | RETAINED PWR | | X | X |
| Signal buffer system | SIGNAL BUFFER | | X | X |
| Panic alarm | PANIC ALARM | | | X |
| TPMS | AIR PRESSUE MONITOR | X | X | X |
Scheme 10
| Service item | Setting item | Setting |
|---|
| ROOM LAMP TIMER SET | MODE 1 | 0 sec. | Sets the interior room lamp ON time. (Timer operating time) |
| MODE 2 | 7.5 sec. |
| MODE 3 (1) | 15 sec. |
| MODE 4 | 30 sec. |
| SET I/L D-UNLCK INTCON | On (1) | With the interior room lamp timer function |
| Off | Without the interior room lamp timer function |
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 2 (1) | 1 sec. |
| MODE 3 | 2 sec. |
| MODE 4 | 3 sec. |
| MODE 5 | 4 sec. |
| MODE 6 | 5 sec. |
| MODE 7 | 0 sec. |
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 2 (1) | 1 sec. |
| MODE 3 | 2 sec. |
| MODE 4 | 3 sec. |
| MODE 5 | 4 sec. |
| MODE 6 | 5 sec. |
| MODE 7 | 0 sec. |
| R LAMP TIMER LOGIC SET | MODE 1 (1) | Interior room lamp timer activates with synchronizing all doors. |
| MODE 2 | Interior room lamp timer activates with synchronizing the driver door only. |
| (1) Factory setting |
