Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are buckled or unbuckled. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS of this Service Information.
| WARNING | Always observe the following items for preventing accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIR BAG SYSTEM ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | Always observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Scheme 23
- When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
- For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
- After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.
Scheme 24
UNIQUE SWITCH
The switch integrates 2 types of LEDs*, filters that pass or absorb specified wavelengths (filter 1, filter 2), and filters adapted to both display colors (filter 3), enabling 2 different symbols to be displayed at a same position by LED changeover.
*: Abbreviation of light emitting diode. It is a semiconductor device that lights up when electric current is applied.
MULTI DISPLAY UNIT INPUT/OUTPUT SINGNAL
| Reception unit | Signal name | Description |
|---|---|---|
| A/C auto amp. | A/C operation signal | Transmits the air conditioner operation status to the A/C auto amp. |
| ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. | |
| A/C ECO setting signal | Transmits the "CLIMATE ECO" ON/OFF status on the SET UP screen of the multi display unit. | |
| ECM (M/T models) | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. | |
| TCM (CVT models) | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. | |
| EPS control unit | ECO mode signal | Transmits the "D-MODE" ECO switch status of the multi display unit. |
| NORMAL mode signal | Transmits the "D-MODE" NORMAL switch status of the multi display unit. | |
| SPORT mode signal | Transmits the "D-MODE" SPORT switch status of the multi display unit. |
OUTPUT SIGNAL CHART
| Transmit unit | Signal name | Description |
|---|---|---|
| A/C auto amp. | A/C display signal | Receives a display signal according to the air conditioner status from the A/C auto amp. |
| ECM | Engine speed signal | Receives the engine speed signal. |
| Engine torque signal | Receives the engine torque signal calculated by ECM. | |
| Fuel consumption monitor signal | Receives the consumption monitor signal calculated by ECM. | |
| Boost pressure signal | Receives the boost pressure signal calculated by ECM. | |
| Engine status signal | Receives the engine status signal. | |
| BCM | Position light request signal | Receives a position light request signal according to the light switch status. |
| ABS actuator and electric unit (control unit) | Decel G sensor signal | Receives the decel. G sensor signal calculated by the ABS actuator and electric unit (control unit). |
| Side G sensor signal | Receives the side G sensor signal calculated by the ABS actuator and electric unit (control unit). | |
| Combination meter | Vehicle speed signal | Receives the vehicle speed signal. |
| Odometer signal | Receives the odometer signal. |
INPUT SIGNAL CHART
DATA MONITOR
Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.
| Monitor item | Unit | Description |
|---|---|---|
| ECO SW | On/Off | Displays the ECO switch signal status sent via CAN communication. |
| NORMAL SW | On/Off | Displays the NORMAL switch signal status sent via CAN communication. |
| SPORTS SW | On/Off | Displays the SPORTS switch signal status sent via CAN communication. |
| BOOST PRESSURE | KPa | Displays the boost pressure signal value received from ECM via CAN communication. |
| ENGINE SPEED | Tr/min | Displays the engine speed signal value received from ECM via CAN communication. |
| ENGINE TORQUE | Nm | Displays the engine torque signal value received from ECM via CAN communication. |
| BATTERY VOLTAGE | V | Displays the input voltage value. |
| FUEL CONSUMPTION | Mm 3 | Displays the fuel consumption signal value received from ECM via CAN communication. |
| VEHICLE SPEED | Km/h | Displays the vehicle speed signal value received from the combination meter via CAN communication. |
| LONG ACC | G | Displays the decel G signal received from ABS actuator and electric unit (control unit) via CAN communication. |
| TRANCE ACC | G | Displays the side G signal received from ABS actuator and electric unit (control unit) via CAN communication. |
| DIST TOTAL | Km | Displays the mileage signal value received from the combination meter via CAN communication. |
| POSI LIGHT REQ | On/Off | Displays the parking lamp signal value received from BCM via CAN communication. |
| CLUSTER ILL REQ | On/Off | Displays the dimming signal value received from BCM via CAN communication. |
| ENGINE STATUS | STOP/STALL/RUN/CRA | Displays the engine status signal value received from ECM via CAN communication. |
| A/C SW (1) | On/Off | Displays the A/C switch signal status sent via CAN communication. |
| AUTO SW (1) | On/Off | Displays the AUTO switch signal status sent via CAN communication. |
| RR DEF SW (1) | On/Off | Displays the RR DEF switch signal status sent via CAN communication. |
| FR DEF SW (1) | On/Off | Displays the FR DEF switch signal status sent via CAN communication. |
| VENT SW1 (1) | On/Off | Displays the air outlet switch signal status sent via CAN communication. |
| VENT SW2 (1) | VENT/B/L/FOOT/D/F | Displays the air outlet switch signal status sent via CAN communication. |
| INTAKE SW (1) | On/Off | Displays the air intake switch signal status sent via CAN communication. |
| INTAKE SW LONG PUSH (1) | On/Off | Displays the air intake switch hold signal status sent via CAN communication. |
| OFF SW (1) | On/Off | Displays the OFF switch signal status sent via CAN communication. |
| TEMP SW1 (1) | On/Off | Displays the temperature control dial signal status sent via CAN communication. |
| FAN SW1 (1) | On/Off | Displays the fan control dial signal status sent via CAN communication. |
| A/C SW IND | On/Off | Displays the A/C switch indicator signal value received from the A/C auto amp. via CAN communication. |
| A/C INDICATOR | On/Off | Displays the A/C display signal value received from the A/C auto amp. via CAN communication. |
| OFF INDICATOR | On/Off | Displays the OFF display signal value received from the A/C auto amp. via CAN communication. |
| AIR VENT IND | Non-display/VENT/B/L/FOOT/D/F/DEF | Displays the air outlet indicator signal value received from the A/C auto amp. via CAN communication. |
| FR DEF SW IND | On/Off | Displays the RF DEF indicator signal value received from the A/C auto amp. via CAN communication. |
| FRE SW IND | On/Off | Displays the FRE indicator signal value received from the A/C auto amp. via CAN communication. |
| REC SW IND | On/Off | Displays the REC indicator signal value received from the A/C auto amp. via CAN communication. |
| RR DEF SW IND | On/Off | Displays the RR DEF indicator signal value received from the IPDM E/R via CAN communication. |
| AUTO IND | Off/Auto | Displays the AUTO indicator signal value received from the A/C auto amp. via CAN communication. |
| TEMP IND | °C | Displays the temperature setting unit signal value received from the A/C auto amp. via CAN communication. |
| FAN IND | Off/speed | Displays the fan setting signal value received from the A/C auto amp. via CAN communication. |
| (1) This is not used to determine ON/OFF of the indicator lamp. | ||
| (1) | This is not used to determine ON/OFF of the indicator lamp. |
PHYSICAL VALUES
Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (Y) 10 (B) 11 (B) Battery power supply Input Ignition switch OFF 9 V - 16 V Battery power supply 2 (V) 10 (B) 11 (B) Illumination signal Input Ignition switch OFF Lighting switch 1ST position. 9 V - 16 V 12 V Lighting switch OFF position. 0 V 0 V 5 (GR) 10 (B) 11 (B) Illumination control signal Input Ignition switch ON Lighting switch 1ST position. When illumination control level is maximum. 0 V - 16 V Lighting switch 1ST position. When illumination control level is midway. Lighting switch 1ST position. When meter illumination is minimum. 12 V 6 (L) - CAN-H - - - - 7 (SB) 10 (B) 11 (B) Ignition power supply Input Ignition switch ON 9 V - 16 V Battery power supply 12 (P) - CAN-L
