Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are buckled or unbuckled.
Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS of this Service Information.
| WARNING | Always observe the following items for preventing accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIR BAG SYSTEM ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | Always observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Scheme 127
- When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
- For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
- After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.
Precaution for Procedure without Cowl Top Cover
When performing the procedure after removing cowl top cover, cover the lower end of windshield with urethane, etc to prevent damage to windshield.
Scheme 128
Commercial Service Tool
Tool name Description Remover tool Remove clips, pawls and metal clips
OUTLINE
Ventilation system is controlled by A/C auto amp. (AUTOMATIC AIR CONDITIONING) or A/C control (MANUAL AIR CONDITIONING). For details of air conditioner system, refer to " SYSTEM DESCRIPTION " (AUTOMATIC AIR CONDITIONING), " SYSTEM DESCRIPTION " (MANUAL AIR CONDITIONING).
Scheme 129
Scheme 130
Models for Canada
| X: Applicable | |||||
|---|---|---|---|---|---|
| MODE/DEF position indication | AIR OUTRET | ||||
| Ventilator | Foot | Defroster (4) | |||
| Center (1) | Side (2) | Front (3) | Rear (3) | ||
| X | X | ||||
| X | X | X | X | ||
| X | X | X | X | ||
| X | X | X | X | ||
| X | X | ||||
Models except for Canada
| MODE/DEF position indication | AIR OUTRET | |||
|---|---|---|---|---|
| Ventilator | Foot (3) | Defroster (4) | ||
| Center (1) | Side (2) | |||
| X | X | |||
| X | X | X | ||
| X | X | X | ||
| X | X | X | ||
| X | X | |||
Scheme 131
Scheme 132
Scheme 133
Scheme 134
- Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-621414-S19239322442014061000000) ".
- Remove fixing screws (A).
- Disengage fixing pawls (A), and then remove center ventilator grille.
In-cabin microfilter
| Replacement interval | " INTRODUCTION OF PERIODIC MAINTENANCE " |
