PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT"
PRE-TENSIONER
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the " SRS AIRBAG " and " SEAT BELTS " of this Service Information.
| WARNING | Always observe the following items for preventing accidental activation. To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision that would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see " SRS AIRBAG ". Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | Always observe the following items for preventing accidental activation. When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Scheme 34
Combination Meter
The buzzer (1) for the warning chime system is integrated in the
Scheme 35
Scheme 36
The combination meter sounds the alarm buzzer installed in the combination meter when receiving the buzzer output signal transmitted from each unit.
BCM
BCM receives signals from various units and transmits a buzzer output signal to the combination meter via CAN communication if it judges that the warning buzzer should be activated.
WARNING CHIME FUNCTION LIST
| Warning functions | Out line | Warning judgment unit | Refer to |
|---|---|---|---|
| Light reminder warning chime | The warning chime sounds when the ignition switch is in OFF or ACC position with the combination switch (lighting switch) in the 1st or 2nd position and the driver side door open. | BCM | " LIGHT REMINDER WARNING CHIME: SYSTEM DESCRIPTION " |
| Seat belt warning chime | The warning chime sounds when the driver seat belt is unfastened with the ignition switch in ON position. | BCM | " SEAT BELT WARNING CHIME: SYSTEM DESCRIPTION " |
| Parking brake release warning chime | The warning chime sounds when the ignition switch is in ON position with the parking brake in operation and the vehicle speed 7 km/h (4.3 MPH) or more. | Combination meter | " PARKING BRAKE RELEASE WARNING CHIME: SYSTEM DESCRIPTION " |
| Key warning chime (Without intelligent key) | The warning chime sounds when the ignition switch is in OFF or ACC position with the key inserted and the driver side door open. | BCM | " KEY WARNING CHIME: SYSTEM DESCRIPTION " |
FAIL-SAFE
The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.
| Function | Specifications | |
|---|---|---|
| Speedometer | Reset to zero by suspending communication. | |
| Tachometer | ||
| Engine coolant temperature gauge | ||
| Illumination control | When suspending communication, changes to nighttime mode. | |
| Shift position indicator | When suspending communication, not indicate. | |
| Information display | Instantaneous fuel consumption | When reception time of an abnormal signal is 2 seconds or less, the last received datum is used for calculation to indicate the result. When reception time of an abnormal signal is more than two seconds, the last result calculated during normal condition is indicated. |
| Average fuel consumption | ||
| Possible driving distance | ||
| Torque distribution indicator | ||
| Buzzer | The buzzer turns OFF by suspending communication. | |
| Warning lamp/indicator lamp | ABS warning lamp | The lamp turns ON by suspending communication. |
| Malfunction indicator lamp | ||
| VDC OFF indicator lamp | ||
| EPS warning lamp | ||
| AWD warning lamp | ||
| Brake warning lamp | ||
| VDC warning lamp | The lamp turns OFF by suspending communication. | |
| High beam indicator lamp | ||
| Turn signal indicator lamp | ||
| Door warning lamp | ||
| Tail lamp indicator lamp | ||
| Engine start operation indicator lamp | ||
| Shift P warning lamp | ||
| Oil pressure warning lamp | ||
| CRUISE indicator lamp | ||
| AWD mode indicator lamp (AWD) | ||
| AWD mode indicator lamp (AWD-V) | ||
| Key warning lamp | ||
| CVT indicator lamp | ||
| Low tire pressure warning lamp | After blinking for 1 minute, the lamp remains ON. | |
Scheme 37
WARNING CHIME CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | ON |
| Combination switch (Lighting switch) | OFF or AUTO position |
| Driver side door | Close [front door switch (driver side) OFF] |
SIGNAL PATH
- BCM requires warning chime output to combination meter when it judges light reminder warning chime is necessary from signals below. Signal name Signal path Ignition switch signal - Combination switch signal Combination switch (Lighting switch) BCM Driver door switch signal Front door switch (driver side) BCM
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal path Buzzer output signal BCM Combination meter
Scheme 38
Scheme 39
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | OFF |
| Seat belt (driver side) | Fastened (driver side seat belt buckle switch OFF) |
| 6 seconds after the start of warning sound | |
- BCM requires warning chime output to combination meter when it judges seat belt warning chime is necessary from signals below. Signal name Signal path Ignition switch signal - Seat belt buckle switch signal (driver side) Seat belt buckle switch (driver side) Combination meter BCM
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal path Buzzer output signal BCM Combination meter
Scheme 40
Scheme 41
Scheme 42
Warning is canceled if any of the following conditions are fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | OFF |
| Parking brake | Release condition (parking brake switch OFF) |
| Vehicle speed | Approximately 3 km/h (1.9 MPH) or less |
Combination meter sounds integrated buzzer when it judges that parking brake release warning chime is necessary from signals below.
| Signal name | Signal path |
|---|---|
| Ignition switch signal | |
| Parking brake switch signal | Parking brake switch Combination meter |
| Vehicle speed signal | ABS actuator and electric unit (control unit) Combination meter |
Scheme 43
Scheme 44
Scheme 45
Warning is canceled if any of the following conditions is fulfilled.
| Operation conditions | |
|---|---|
| Ignition switch | ON |
| Key switch | OFF (state that removed key from key cylinder) |
| Driver side door | Close [front door switch (driver side) OFF] |
- BCM requires warning chime output to combination meter when it judges key warning chime is necessary from signals below. Signal name Signal path Ignition switch signal - Key switch signal Key switch BCM Driver door switch signal Front door switch (driver side) BCM
- Combination meter sounds integrated buzzer, following the warning chime output requirement (below signal) from BCM. Signal name Signal path Buzzer output signal BCM Combination meter
Scheme 46
Scheme 47
SELF DIAG RESULT
Refer to " DTC INDEX ".
Display Item List
| X: Applicable | ||
|---|---|---|
| Display item [Unit] | MAIN SIGNALS | Description |
| SPEED METER [km/h] | X | Value of vehicle speed signal received from ABS actuator and electric unit (control unit) via CAN communication. NOTE: 655.35 is displayed when the malfunction signal is received. |
| SPEED OUTPUT [km/h] | X | Vehicle speed signal value transmitted to other units via CAN communication. NOTE: 655.35 is displayed when the malfunction signal is received. |
| ODO OUTPUT [km/h or mph] | Odometer signal value transmitted to other units via CAN communication. | |
| TACHO METER [rpm] | X | Value of the engine speed signal received from ECM via CAN communication. NOTE: 8191.875 is displayed when the malfunction signal is received. |
| FUEL METER [L] | X | Fuel level indicated on combination meter. |
| W TEMP METER [°C] | X | Value of engine coolant temperature signal is received from ECM via CAN communication. NOTE: 215 is displayed when the malfunction signal is input. |
| FUEL CAP W/L [On/Off] | Status of fuel filler cap warning display detected from fuel filler cap warning display signal received from ECM via CAN communication. | |
| ABS W/L [On/Off] | Status of ABS warning lamp detected from ABS warning lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. | |
| VDC/TCS IND [On/Off] | Status of VDC OFF indicator lamp detected from VDC OFF indicator lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. | |
| SLIP IND [On/Off] | Status of VDC warning lamp detected from VDC warning lamp signal received from ABS actuator and electric unit (control unit) via CAN communication. | |
| BRAKE W/L [On/Off] | Status of brake warning lamp detected from brake warning lamp signal is received from ABS actuator and electric unit (control unit) via CAN communication. NOTE: Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. | |
| DOOR W/L [On/Off] | Status of door open warning lamp detected from door switch signal received from BCM via CAN communication. | |
| HI-BEAM IND [On/Off] | Status of high beam indicator lamp detected from high beam request signal is received from BCM via CAN communication. | |
| TURN IND [On/Off] | Status of turn indicator lamp detected from turn indicator signal is received from BCM via CAN communication. | |
| LIGHT IND [On/Off] | Status of tail lamp indicator lamp detected from position light request signal is received from BCM via CAN communication. | |
| OIL W/L [On/Off] | Status of oil pressure warning lamp detected from oil pressure warning lamp signal is received from ECM via CAN communication. | |
| MIL [On/Off] | Status of malfunction indicator lamp detected from malfunctioning indicator lamp signal is received from ECM via CAN communication. | |
| GLOW IND [Off] | This item is displayed, but cannot be monitored. | |
| C-ENG2 W/L [Off] | This item is displayed, but cannot be monitored. | |
| CRUISE IND [On/Off] | Status of CRUISE indicator lamp detected from ASCD status signal is received from ECM via CAN communication. | |
| SET IND [Off] | This item is displayed, but cannot be monitored. | |
| CVT IND [On/Off] | Status of CVT indicator lamp detected from CVT status signal is received from TCM via CAN communication. | |
| 4WD W/L [On/Off] | Status of AWD warning lamp judged from AWD warning lamp signal received from AWD control module with CAN communication line. | |
| 4WD LOCK IND [On/Off] | Status of AWD mode indicator lamp (AWD-V) judged from AWD mode indicator signal received from AWD control module with CAN communication line. | |
| FUEL W/L [On/Off] | Low fuel warning status detected by the identified fuel level. | |
| AIR PRES W/L [On/Off] | Status of low tire pressure warning lamp judged from low tire pressure warning lamp signal received from BCM from CAN communication line. | |
| KEY G/Y W/L [On/Off] | Status of KEY warning lamp (G/Y) detected from KEY warning lamp signal is received from BCM via CAN communication. | |
| KEY KNOB W/L [On/Off] | Status of shift P warning lamp detected from shift P warning lamp signal is received from BCM via CAN communication. | |
| EPS W/L [On/Off] | Status of EPS warning lamp detected from EPS warning lamp signal is received from EPS control unit via CAN communication. | |
| DPF W/L [Off] | This item is displayed, but cannot be monitored. | |
| LCD [B&P N, B&P I, SFT P, BATT, NO KY, LK WN] (1) [C&P N, C&P I, SFT P, BATT, NO KY, LK WN] (2) | Status of engine start operation indicator lamp, shift P warning lamp and KEY warning lamp, detected from engine start operation indicator lamp signal, shift P warning lamp signal and KEY warning lamp signal are received from BCM via CAN communication. | |
| SHIFT IND [P, R, N, D, M1, M2, M3, M4, M5, M6] | Status of shift position indicator judged from shift position signal received from TCM with CAN communication line. | |
| O/D OFF SW [Off] | This item is displayed, but cannot be monitored. | |
| M RANGE SW [On/Off] | Status of manual mode switch. | |
| NM RANGE SW [On/Off] | Status of non-manual mode switch. | |
| AT SFT UP SW [On/Off] | Status of manual mode shift up switch. | |
| AT SFT DWN SW [On/Off] | Status of manual mode shift down switch. | |
| PKB SW [On/Off] | Status of parking brake switch. | |
| BUCKLE SW [On/Off] | Status of seat belt buckle switch (driver side). | |
| BRAKE SW [Off] | This item is displayed, but cannot be monitored. | |
| BRAKE OIL SW [On/Off] | Status of brake fluid level switch. | |
| A/C AMP CONN [On/Off] | Status of A/C auto amp. connection recognition signal. | |
| PASS BUCKLE SW [Off] | This item is displayed, but cannot be monitored. | |
| DISTANCE [km] | Value of distance to empty calculated by combination meter. | |
| OUTSIDE TEMP [°C or °F] | Ambient temperature value converted from ambient sensor signal received from ambient sensor. NOTE: This may not match with the temperature value indicated on the information display. (Because the information display value is a corrected value from the ambient sensor input value.) | |
| FUEL LOW SIG [On/Off] | Status of fuel level low warning signal to output to AV control unit via CAN communication. | |
| BUZZER [On/Off] | X | Buzzer status (in the combination meter) is detected from the buzzer output signal received from each unit via CAN communication and the warning output condition of the combination meter. |
| ASCD SPD BLNK [On/Off] | Blinking status of ASCD or speed limiter set vehicle speed that is judged by the ASCD status signal received from ECM via CAN communication. | |
| ASCD STATUS [Off, ASCD, CRUISE, SL ON, SL SET] | Display status of ASCD and speed limiter status display judged by the ASCD status signal received from ECM via CAN communication. | |
| ASCD REQ SPD [km/h/Off] | ASCD or speed limiter set vehicle speed value that is judged by the ASCD status signal received from ECM via CAN communication. | |
| TPMS PRESS L [On/Off] | Status of low tire pressure warning judged from low tire pressure warning lamp signal received from BCM with CAN communication line. | |
| (1) CVT models (2) M/T models | ||
| NOTE |
|---|
| 655.35 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 655.35 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 8191.875 is displayed when the malfunction signal is received. |
| NOTE |
|---|
| 215 is displayed when the malfunction signal is input. |
| NOTE |
|---|
| Displays "Off" if the brake warning lamp is illuminated when the valve check starts, the parking brake switch is turned ON or the brake fluid level switch is turned ON. |
| NOTE |
|---|
| This may not match with the temperature value indicated on the information display. (Because the information display value is a corrected value from the ambient sensor input value.) |
| (1) | CVT models |
| (2) | M/T models |
Note. Some items are not available according to vehicle specification.
W/L ON HISTORY
- Stores histories when warning/indicator lamp is turned on.
- "W/L ON HISTORY" indicates the "TIME" when the warning/indicator lamp is turned on.
- The "TIME" above is: 0: The condition that the warning/indicator lamp has been turned on 1 or more times after starting the engine and waiting for 30 seconds. 1 - 39: The number of times the engine was restarted after the 0 condition. NO W/L ON HISTORY: Stores NO (0) turning on history of warning/indicator lamp.
Note. W/L ON HISTORY is not stored for approximately 30 seconds after the engine starts. Brake warning lamp does not store any history when the parking brake is applied or the brake fluid level gets low.
Display Item
| Display item | Description |
|---|---|
| ABS W/L | Lighting history of ABS warning lamp. |
| VDC/TCS IND | Lighting history of VDC OFF indicator lamp. |
| SLIP IND | Lighting history of VDC warning lamp. |
| BRAKE W/L | Lighting history of brake warning lamp. |
| DOOR W/L | Lighting history of door open warning. |
| OIL W/L | Lighting history of oil pressure warning lamp. |
| C-ENG W/L | Lighting history of malfunction indicator lamp. |
| CRUISE IND | Lighting history of CRUISE indicator lamp. |
| CVT IND | Lighting history of CVT indicator lamp. |
| 4WD W/L | Lighting history of AWD warning lamp. |
| FUEL W/L | Lighting history of low fuel level warning lamp. |
| AIR PRES W/L | Lighting history of low tire pressure warning lamp. |
| KEY G/Y W/L | Lighting history of KEY warning lamp (G/Y). |
| KEY KNOB W/L | Lighting history of Shift P warning lamp. |
| EPS W/L | Lighting history of EPS warning lamp. |
Note. In items displayed on the CONSULT screen, only those listed in the above table are used.
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT.
| CONSULT screen item | Indication/Unit | Description | |
|---|---|---|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected | |
| Odo/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected | |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected | While turning BCM status from low power consumption mode to normal mode (Power position is "LOCK" (1) .) |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode (Power position is "OFF".) | ||
| LOCK>ACC | While turning power position from "LOCK" (1) *to "ACC" | ||
| ACC>ON | While turning power position from "ACC" to "IGN" | ||
| RUN>ACC | While turning power position from "RUN" to "ACC" (Vehicle is stopping and selector lever is except P position.) | ||
| CRANK>RUN | While turning power position from "CRANKING" to "RUN" (From cranking up the engine to run it) | ||
| RUN>URGENT | While turning power position from "RUN" to "ACC" (Emergency stop operation) | ||
| ACC>OFF | While turning power position from "ACC" to "OFF" | ||
| OFF>LOCK | While turning power position from "OFF" to "LOCK" (1) | ||
| OFF>ACC | While turning power position from "OFF" to "ACC" | ||
| ON>CRANK | While turning power position from "IGN" to "CRANKING" | ||
| OFF>SLEEP | While turning BCM status from normal mode (Power position is "OFF".) to low power consumption mode | ||
| LOCK>SLEEP | While turning BCM status from normal mode (Power position is "LOCK" (1) .) to low power consumption mode | ||
| LOCK | Power position is "LOCK" (1) | ||
| OFF | Power position is "OFF" (Ignition switch OFF) | ||
| ACC | Power position is "ACC" (Ignition switch ACC) | ||
| ON | Power position is "IGN" (Ignition switch ON with engine stopped) | ||
| ENGINE RUN | Power position is "RUN" (Ignition switch ON with engine running) | ||
| CRANKING | Power position is "CRANKING" (At engine cranking) | ||
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. | |
| (1) Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. Closing door Opening door Door is locked using door request switch Door is locked using Intelligent Key The power position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "LOCK". | |||
| (1) | Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. |
DATA MONITOR
| Display item [Unit] | Description |
|---|---|
| PUSH SW [On/Off] | Status of push-button ignition switch judged by BCM. |
| UNLK SEN-DR [On/Off] | Status of unlock sensor judged by BCM. |
| VEH SPEED 1 [km/h] | Value of vehicle speed signal received from combination meter with CAN communication line. |
| TAIL LAMP SW [On/Off] | Status of lighting switch judged by BCM using the combination switch readout function. |
| FR FOG SW [On/Off] | Status of front fog lamp switch judged by BCM using the combination switch readout function. |
| DOOR SW-DR [On/Off] | Status of driver side door switch judged by BCM. |
| CDL LOCK SW [On/Off] | Status of door lock unlock switch judged by BCM. |
| Display item [Unit] | Description |
|---|---|
| IGN ON SW [On/Off] | Status of ignition switch judged by BCM. |
| KEY ON SW [On/Off] | Status of key switch judged by BCM. |
| DOOR SW-DR [km/h] | Status of driver side door switch judged by BCM. |
| REVERSE SW CAN [On/Off] | This item is displayed, but cannot be monitored. |
| TAIL LAMP SW [On/Off] | Status of lighting switch judged by BCM using the combination switch readout function. |
| FR FOG SW [On/Off] | Status of front fog lamp switch judged by BCM using the combination switch readout function. |
| BUCKLE SW [On/Off] | Status of seat belt buckle switch (driver side) received from combination meter with CAN communication line. |
| VEHICLE SPEED [km/h] | Value of vehicle speed signal received from combination meter with CAN communication line. |
PHYSICAL VALUES
Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (L) - CAN-H - - - - 2 (P) - CAN-L - - - - 4(Y) Ground Vehicle speed signal (8-pulse) Output Ignition switch ON Speedometer operated [When vehicle speed is approx. 40 km/h (25 MPH)] NOTE: The maximum voltage varies depending on the specification (destination unit). 6 (BR) Ground Fuel level sensor signal Input Ignition switch ON - 2WD AWD 7 (R) Ground Air bag signal Input Ignition switch ON Air bag warning lamp ON 4 V Air bag warning lamp OFF 0 V 8 (1) (Y) - - - - - - 9 (O) Ground Seat belt buckle switch signal (driver side) Input Engine idling When driver seat belt is fastened. 12 V When driver seat belt is unfastened. 0 V 10 (SB) Ground Parking brake switch signal Input Ignition switch ON Parking brake applied. 0 V Parking brake released. 5 V 11 (G) Ground Brake fluid level switch signal Input Ignition switch ON Brake fluid level is normal 5 V Brake fluid level is less than LOW level 0 V 13 (B) Ground Illumination control signal Output Ignition switch ON Lighting switch 1ST When meter illumination is maximum Lighting switch 1ST When meter illumination is step 6 Lighting switch 1ST When meter illumination is minimum 12 V 14 (V) Ground Manual mode shift up signal Input Ignition switch ON Selector lever UP operation 0 V Other than the above 12 V 15 (L) Ground ACC power supply Input Ignition switch ACC - Battery voltage 16 (O) Ground Manual mode shift down signal Input Ignition switch ON Selector lever DOWN operation 0 V Other than the above 12 V 17 (W) Ground Washer level switch signal Input Ignition switch ON Low washer fluid warning lamp ON 0 V Low washer fluid warning lamp OFF 12 V 18 (R) Ground Security signal Input Ignition switch ON Security indicator lamp ON 0 V Security indicator lamp OFF 12 V 19 (GR) Ground Ambient sensor signal Input Ignition switch ON Changes depending to ambient temperature. 20 (LG) Ground Ambient sensor ground - Ignition switch ON - 0 V 21 (B) Ground Ground - Ignition switch ON - 0 V 22 (B) Ground Ground - Ignition switch ON - 0 V 23 (B) Ground Ground - Ignition switch ON - 0 V 24 (L) Ground Fuel level sensor ground - Ignition switch ON - 0 V 25 (B) Ground VDC ground - Ignition switch ON - 0 V 27 (LG) Ground Battery power supply Input Ignition switch OFF - Battery voltage 28 (GR) Ground Ignition signal Input Ignition switch ON - Battery voltage 31 (P) Ground A/C auto amp. connection recognition signal Input Ignition switch ON - 5 V 36 (LG) Ground Manual mode signal Input Ignition switch ON Selector manual mode position 0 V Other than the above 12 V 37 (Y) Ground Non-manual mode signal Input Ignition switch ON Selector manual mode position 12 V Other than the above 0 V 38 (P) Ground Alternator signal Input Ignition switch ON Charge warning lamp ON 2 V Charge warning lamp OFF 12 V (1) This harness is not used
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.
| Function | Specifications | |
|---|---|---|
| Speedometer | Reset to zero by suspending communication. | |
| Tachometer | ||
| Engine coolant temperature gauge | ||
| Illumination control | When suspending communication, changes to nighttime mode. | |
| Shift position indicator | When suspending communication, not indicate. | |
| Information display | Instantaneous fuel consumption | When reception time of an abnormal signal is 2 seconds or less, the last received datum is used for calculation to indicate the result. When reception time of an abnormal signal is more than two seconds, the last result calculated during normal condition is indicated. |
| Average fuel consumption | ||
| Possible driving distance | ||
| Torque distribution indicator | ||
| Low tire pressure warning | The display turns OFF by suspending communication. | |
| Buzzer | The buzzer turns OFF by suspending communication. | |
| Warning lamp/indicator lamp | ABS warning lamp | The lamp turns ON by suspending communication. |
| Malfunction indicator lamp | ||
| VDC OFF indicator lamp | ||
| EPS warning lamp | ||
| AWD warning lamp | ||
| Brake warning lamp | ||
| VDC warning lamp | The lamp turns OFF by suspending communication. | |
| High beam indicator lamp | ||
| Turn signal indicator lamp | ||
| Door warning lamp | ||
| Tail lamp indicator lamp | ||
| Engine start operation indicator lamp | ||
| Shift P warning lamp | ||
| Oil pressure warning lamp | ||
| CRUISE indicator lamp | ||
| AWD mode indicator lamp (AWD) | ||
| AWD mode indicator lamp (AWD-V) | ||
| Key warning lamp | ||
| CVT indicator lamp | ||
| Low tire pressure warning lamp | After blinking for 1 minute, the lamp remains ON. | |
List of ECU Reference
| ECU | Reference | |
|---|---|---|
| BCM | With intelligent key models | " REFERENCE VALUE " |
| " FAIL-SAFE " | ||
| " DTC INSPECTION PRIORITY CHART " | ||
| " DTC INDEX " | ||
| Without intelligent key models | " REFERENCE VALUE " | |
| " FAIL-SAFE " | ||
| " DTC INSPECTION PRIORITY CHART " | ||
| " DTC INDEX " | ||
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much information as possible about the conditions and environment under which the malfunction occurred. GO TO 2.
- CHECK SYMPTOM Check the symptom based on the information obtained from the customer. Check if any other malfunctions are present. GO TO 3.
- CHECK CONSULT SELF-DIAGNOSIS RESULTS Connect CONSULT and perform self-diagnosis. Refer to " «BUZZER: CONSULT FUNCTION (BCM - BUZZER)»(ref-516454-S17538543792012120600000) " (with intelligent key system) or " «BUZZER: CONSULT FUNCTION (BCM - BUZZER)»(ref-516454-S41600987722012120600000) " (without intelligent key system). When DTC is detected, follow the instructions below: Record DTC and Freeze Frame Data. Are self-diagnosis results normal? YES: GO TO 4. NO: GO TO 5 .
- NARROW DOWN MALFUNCTIONING PARTS BY SYMPTOM DIAGNOSIS Perform symptom diagnosis and narrow down the malfunctioning parts. GO TO 5.
- REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace malfunctioning parts. NOTE: If DTC is displayed, erase DTC after repairing or replacing malfunctioning parts. GO TO 6.
- FINAL CHECK Check that the warning buzzer in the combination meter operates normally. Does it operate normally? YES: INSPECTION END NO: GO TO 1 .
Component Function Check
- CHECK OPERATION OF METER BUZZER Select "BUZZER" of "BCM" on CONSULT. Perform "LIGHT WARN ALM" of "Active Test". Does meter buzzer beep? YES: INSPECTION END NO: GO TO 2.
- CHECK COMBINATION METER INPUT SIGNAL Select the "Data Monitor" for the "METER/M&A" and check the "BUZZER" monitor value. BUZZER Under the condition of buzzer input: On Except above: Off Is the inspection result normal? YES: Replace combination meter. NO: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-516421-S18255733352012120600000) " (WITH INTELLIGENT KEY SYSTEM) or " «REMOVAL AND INSTALLATION»(ref-516451-S34818918942012120600000) " (WITHOUT INTELLIGENT KEY SYSTEM).
- CHECK COMBINATION METER INPUT SIGNAL Select the "Data Monitor" for the "METER/M&A" and check the "BUCKLE SW" monitor value. BUCKLE SW When driver seat belt is fastened: Off When driver seat belt is unfastened: On INSPECTION END
