Interior Lighting System: Removal & Installation Nissan Juke I

Interior/illumination Lights 4 illustrations ~197 words

Removal and Installation

CAUTIONDisconnect the battery negative terminal or the fuse.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3
  1. Remove the lens (1). Insert a remover tool (A) into the gap between the lens. Disengage the lens fixing pawls, and then remove the lens. CAUTION: Use a remover tool wrapped in tape.
  2. Press pawl in the direction shown by the arrow in the figure using a remover tool (A), and then pull the map lamp housing (1) in the direction shown by the arrow in the figure. CAUTION: Use a remover tool wrapped in tape.
  3. Disconnect map lamp harness connector, and then remove map lamp housing.

INSTALLATION

Install in the reverse order of removal.

Replacement

CAUTIONDisconnect battery negative terminal or the fuse. Never touch glass of bulb directly by hand. Keep grease and other oily matters away from it. Never touch bulb by hand while it is lit or right after being turned off. Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with new one.
CAUTIONDisconnect the battery cable from negative terminal or remove the fuse.

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL
  1. Insert a remover tool (A) into the gap between luggage room lamp and luggage side lower finisher RH.
  2. Disengage luggage room lamp fixing pawl, and then disconnect luggage room lamp harness connector.
  3. Remove luggage room lamp from luggage side lower finisher RH.

Install in the reverse order of removal.

CAUTIONDisconnect the battery cable from negative terminal or remove the fuse. Never touch the glass of bulb directly by hand. Keep grease and other oily substaces away from it. Never touch bulb by hand while it is lit or right after it is off. Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect the performance of lamp. When replacing bulb, be sure to replace it with a new one.

Scheme 5

Scheme 5: LUGGAGE ROOM LAMP BULB
Scheme 5: LUGGAGE ROOM LAMP BULB
  1. Remove the luggage room lamp.
  2. Insert a remover tool (A) into the gap between the lens and bulb housing, and then disengage fixing pawls as shown by the arrow in the figure.
  3. Remove the bulb.
