CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diagnostic Worksheet during the interview to document the facts and conditions when the noise occurs and any customer comments. Refer to " DIAGNOSTIC WORKSHEET ". This information is necessary to duplicate the conditions that exist when the noise occurs.
- The customer may not be able to provide a detailed description or the location of the noise. Attempt to obtain all the facts and conditions that exist when the noise occurs (or does not occur).
- If there is more than one noise in the vehicle, perform a diagnosis and repair the noise that the customer is concerned about. This can be accomplished by performing a test drive with the customer.
- After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics are provided so that the customer, service adviser, and technician use the same language when describing the noise.
- Squeak - (Like tennis shoes on a clean floor) Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard surfaces = high-pitched noise/softer surfaces = low-pitched noises/edge to surface = chirping
- Creak - (Like walking on an old wooden floor) Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch dependent on materials/often brought on by activity.
- Rattle - (Like shaking a baby rattle) Rattle characteristics include fast repeated contact/vibration or similar movement/loose parts/missing clip or fastener/incorrect clearance.
- Knock - (Like a knock on a door) Knock characteristics include hollow sounds/sometimes repeating/often brought on by driver action.
- Tick - (Like a clock second hand) Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver action or road conditions.
- Thump - (Heavy, muffled knock noise) Thump characteristics include softer knock/dull sounds often brought on by activity.
- Buzz - (Like a bumblebee) Buzz characteristics include high frequency rattle/firm contact.
- Often the degree of acceptable noise level varies depending upon the person. A noise that a technician may judge as acceptable may be very irritating to a customer.
- Weather conditions, especially humidity and temperature, may have a great effect on noise level.
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related to the concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
REPAIR THE CAUSE
- If the cause is a loose component, tighten the component securely.
- If the cause is insufficient clearance between components: Separate components by repositioning or loosening and retightening the components, if possible. Insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape, or urethane tape. A NISSAN Squeak and Rattle Kit (J-43980) is available through the authorized NISSAN Parts Department.
| CAUTION | Never use excessive force as many components are constructed of plastic and may be damaged. |
Note. Always check with the Parts Department for the latest parts information.
The following materials are contained in the NISSAN Squeak and Rattle Kit (J-43980). Each item can be ordered separately as needed.
URETHANE PADS [1.5 mm (0.059 in) thick]
Insulates connectors, harness, etc.
- 76268-9E005: 100 x 135 mm (3.937 x 5.315 in)
- 76884-71L01: 60 x 85 mm (2.362 x 3.346 in)
- 76884-71L02: 15 x 25 mm (0.591 x 0.984 in)
INSULATOR (Foam blocks)
Insulates components from contact. Can be used to fill space behind a panel.
- 73982-9E000: 45 mm (1.772 in) thick, 50 x 50 mm (1.969 x 1.969 in)
- 73982-50Y00: 10 mm (0.394 in) thick, 50 x 50 mm (1.969 x 1.969 in)
INSULATOR (Light foam block)
80845-71L00: 30 mm (1.18 in) thick, 30 x 50 mm (1.181 x 1.969 in)
FELT CLOTHTAPE
Used to insulate where movement does not occur. Ideal for instrument panel applications.
- 68370-4B000: 15 x 25 mm (0.591 x 0.984 in) pad
- 68239-13E00: 5 mm (0.197 in) wide tape roll
The following materials, not found in the kit, can also be used to repair squeaks and rattles.
UHMW (TEFLON) TAPE
Insulates where slight movement is present. Ideal for instrument panel applications.
SILICONE GREASE
Used in place of UHMW tape that is visible or does not fit. Only lasts a few months.
SILICONE SPRAY
Used when grease cannot be applied.
DUCT TAPE
Used to eliminate movement.
CONFIRM THE REPAIR
After repair is complete, test drive the vehicle to confirm that the cause of noise is repaired by test driving the vehicle. Operate the vehicle under the same conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between
- The cluster lid A and instrument panel
- Acrylic lens and combination meter housing
- Instrument panel to front pillar garnish
- Instrument panel to windshield
- Instrument panel mounting pins
- Wiring harnesses behind the combination meter
- A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by pressing on the components while driving to stop the noise. Most of these incidents can be repaired by applying felt cloth tape or silicon spray (in hard to reach areas). Urethane pads can be used to insulate wiring harness.
| CAUTION | Never use silicone spray to isolate a squeak or rattle. If the area is saturated with silicone, the recheck of repair becomes impossible. |
CENTER CONSOLE
Components to check include
- Shifter assembly cover to finisher
- A/C control unit and cluster lid C
- Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Check the following items
- Finisher and inner panel making a slapping noise
- Inside handle escutcheon connection to door finisher
- Wiring harnesses tapping
- Door striker out of alignment causing a popping noise on starts and stops
Tapping, moving the components, or pressing on them while driving to duplicate the conditions can isolate many of these incidents. The areas can usually be insulated with felt cloth tape or insulator foam blocks from the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the customer.
In addition check for the following items
- Trunk lid dumpers out of adjustment
- Trunk lid striker out of adjustment
- Trunk lid torsion bars knocking together
- A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing, or insulating the item(s) or component(s) causing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following items
- Sunroof lid, rail, linkage, or seals making a rattle or light knocking noise
- Sunvisor shaft shaking in the holder
- Front or rear windshield touching headlining and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these incidents. Repairs usually consist of insulating with felt cloth tape.
SEATS
When isolating seat noise it is important to note the position the seat is in and the load placed on the seat when the noise occurs. These conditions should be duplicated when verifying and isolating the cause of the noise.
Causes of seat noise include
- Headrest rods and holder
- A squeak between the seat pad cushion and frame
- The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the conditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then transmitted into the passenger compartment.
Causes of transmitted underhood noise include
- Any component mounted to the engine wall
- Components that pass through the engine wall
- Engine wall mounts and connectors
- Loose radiator mounting pins
- Hood bumpers out of adjustment
- Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best method is to secure, move, or insulate one component at a time and test drive the vehicle. Also, engine RPM or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or insulating the component causing the noise.
