Power Supply, Ground & Circuit Elements: Removal & Installation Nissan Juke I

Body Electrical 3 illustrations ~266 words

How To Remove Extended Storage Switch

Type A

Scheme 1

Scheme 1: How To Remove Extended Storage Switch
Scheme 1: How To Remove Extended Storage Switch
  1. Turn the ignition switch OFF.
  2. Turn the extended storage switch OFF.
  3. Press pawl (A) and tilt to disengage the extended storage switch. Press pawl (B) and tilt to remove the extended storage switch. NOTE: Extended storage switch and fuse are removed together. Remove fuse from extended storage switch, if necessary. Extended storage switch is for transportation and storage. Reinstallation is not required after the removal.

Type B

Scheme 2

Scheme 2
Scheme 2
  1. Turn the ignition switch OFF.
  2. Turn the extended storage switch OFF.
  3. Hold (A) and pull up the extended storage switch hard in (B) direction. NOTE: Extended storage switch and fuse may be removed together. Remove fuse from extended storage switch, if necessary. Extended storage switch is for transportation and storage. Reinstallation is not required after the removal.

REMOVAL

  1. Disconnect the battery cable from the negative terminal. CAUTION: When disconnecting, disconnect the battery cable from the negative terminal first.
  2. Remove cover of battery positive terminal.
  3. Disconnect the battery cable from the positive terminal.
  4. Remove battery fix frame mounting nuts and battery fix frame.
  5. Remove battery.

INSTALLATION

Install in the reverse order of removal.

CAUTIONTo install the battery, carefully read the following instructions. When connecting, connect the battery cable to the positive terminal first. After connecting battery cables, ensure that they are tightly clamped to battery terminals for good contact. Check battery terminal for poor connection caused by corrosion.

Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: REQUIRED PROCEDURE AFTER BATTERY DISCONNECTION ".

Scheme 3

Scheme 3: Exploded View
Scheme 3: Exploded View
  1. Disconnect the battery cable from the negative terminal.
  2. Remove cover of battery positive terminal.
  3. Remove harness mounting nut and battery terminal with fusible link mounting nut.
  4. Disconnect harness connector and remove battery terminal with fusible link.

Install in the reverse order of removal.
