Heater & Automatic Air Conditioning: Removal & Installation Nissan Juke I

Automatic HVAC System 9 illustrations ~443 words

REMOVAL

Remove multi display unit. Refer to " REMOVAL AND INSTALLATION ".

INSTALLATION

Install in the reverse order of removal.

Scheme 78

Scheme 78: REMOVAL
Scheme 78: REMOVAL
  1. Remove audio unit. Refer to the following. Refer to " «REMOVAL AND INSTALLATION»(ref-516455-S24569641952012120600000) ". (Without navigation) Refer to " «REMOVAL AND INSTALLATION»(ref-516456-S36975327102012120600000) ". (With navigation)
  2. Remove inside key antenna (instrument center). Refer to " «INSTRUMENT CENTER: REMOVAL AND INSTALLATION»(ref-516400-S16286760362012120600000) ".
  3. Remove fixing screws (A), and then remove A/C auto amp..

Install in the reverse order of removal.

Scheme 79

Scheme 79: REMOVAL
Scheme 79: REMOVAL
  1. Remove bumper fascia assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-516396-S40930624872012120600000) ".
  2. Disengage fixing pawl, and then remove ambient sensor (1).
  3. Disconnect ambient sensor connector (2), and then remove ambient sensor.

Install in the reverse order of removal.

  1. Remove instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  2. Remove fixing screw, and then remove in-vehicle sensor.

Install in the reverse order of removal.

  1. Remove switch panel. Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  2. Disconnect sunload sensor connector, and then remove sunload sensor.

Install in the reverse order of removal.

  1. Remove evaporator assembly. Refer to " «EVAPORATOR: REMOVAL AND INSTALLATION»(ref-516410-S40108135552012120600000) ".
  2. Remove intake sensor from evaporator.

Note the following items, and then install in the order of removal.

CAUTIONReplace O-rings with new ones. Then apply the compressor oil to them when installing. Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sensor can be located in the same position. Never rotate the bracket insertion part when removing and installing the intake sensor. Check for leakages when recharging refrigerant. Refer to " LEAK TEST ".

Refer to " REFRIGERANT PRESSURE SENSOR: REMOVAL AND INSTALLATION ".

Install in the reverse order of removal.

Scheme 80

Scheme 80: Exploded View
Scheme 80: Exploded View

Scheme 81

Scheme 81: REMOVAL
Scheme 81: REMOVAL
  1. Remove instrument panel assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  2. Disconnect power transistor connector.
  3. Slide power transistor (1) to the left while pressing lever (A), and then remove power transistor.

Install in the reverse order of removal.

Scheme 82

Scheme 82: LEFT SIDE
Scheme 82: LEFT SIDE

Scheme 83

Scheme 83: RIGHT SIDE
Scheme 83: RIGHT SIDE

Scheme 84

Scheme 84: REMOVAL
Scheme 84: REMOVAL
  1. Remove instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  2. Remove fixing screws (A), and then remove intake door motor (1).
  3. Disconnect intake door motor connector (2).

Install in the reverse order of removal.

Scheme 85

Scheme 85: REMOVAL
Scheme 85: REMOVAL
  1. Remove glove box assembly Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  2. Remove foot duct RH. Refer to " «FOOT DUCT: REMOVAL AND INSTALLATION»(ref-516438-S06231903802012120600000) ".
  3. Disconnect mode link rod from mode door motor.
  4. Remove fixing screws (A), and then remove mode door motor (1).
  5. Disconnect mode door motor connector (2).

Install in the reverse order of removal.

Scheme 86

Scheme 86: REMOVAL
Scheme 86: REMOVAL
  1. Set the temperature at full cold. CAUTION: Always perform the above procedure when removing air mix door motor. Otherwise, air mix door may interfere in A/C unit assembly may be damaged.
  2. Remove instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-516429-S05150829502012120600000) ".
  3. Remove fixing screws (A), and then remove air mix door motor (1).
  4. Disconnect air mix door motor connector (2).

Note the following item, and then install in the reverse order of removal.

CAUTIONAfter installing door motor, perform door motor starting position. Refer to " WORK PROCEDURE ".
