RELAY LOCATIONS
For relay locations refer to the component number or connector identification, refer to illustrations (Scheme 29) and see scheme 42.
| Component (No.)/(Connector ID.) | Location |
|---|
| Accessory Relay | In fuse block (J/B). see scheme 40 |
| Air Cut Solenoid Valve Relay (1) | In fuse & relay box. (Scheme 29) |
| Air Pump Relay (37) | In fuse & relay box. (Scheme 29) |
| Back-Up Light Relay (B55) | Left side of luggage compartment. see scheme 39 |
| Blower Relay | In fuse block (J/B). see scheme 40 |
| Cooling Fan Relay No. 1 (14) | Left rear of engine compartment. (Scheme 29) |
| Cooling Fan Relay No. 2 (15) | Left rear of engine compartment. (Scheme 29) |
| Daytime Light Relay (E84) | Right rear of engine compartment. see scheme 38 |
| Heated Seat Relay (M70) | Center of dash. see scheme 37 |
| Horn Relay 1 (E11) | On fuse, fusible link & relay block. (Scheme 30) |
| Horn Relay 2 (E18) | Left rear of engine compartment. see scheme 38 |
| Ignition Relay | In fuse block (J/B). see scheme 40 |
| Intelligent Key Warning Buzzer (E/R) (E62) | Right front of engine compartment. see scheme 38 |
| Rear Window Defogger Relay | In fuse block (J/B). see scheme 40 |
| Starter Control Relay | In IPDM E/R. see scheme 42 |
| TCM Relay (B54) | Left side of luggage compartment. see scheme 39 |
IDENTIFYING RELAYS LOCATION
Note. For approximate component location, match connector identification with connector location within the wiring harness illustrations.
Scheme 29
Scheme 30
Scheme 31
Scheme 31: COMPONENT VIEWS
| Item No. | Component |
|---|
| 1 | Air cut solenoid valve relay |
| 2 | Air pump relay |
| 3 | Air pump cleaner |
| 4 | IPDM (Intelligent Power Distribution Module) |
Scheme 32
| Item No. | Component |
|---|
| 1 | Cooling fan relay-1 |
| 2 | Cooling fan relay-2 |
Scheme 33
| Item No. | Components |
|---|
| 1 | Air cut solenoid valve relay |
| 2 | Recirculation valve (Bank 1) |
| 3 | Refrigerant pressure sensor |
| 4 | Mass air flow sensor (with intake air temperature sensor) (Bank 1) |
| 5 | Power steering pressure sensor |
| 6 | EVAP canister purge volume control solenoid valve |
| 7 | Cooling fan motor |
| 8 | Cooling fan control module |
| 9 | Intake valve timing control solenoid valve |
| 10 | Turbocharger boost control solenoid valve |
| 11 | Mass air flow sensor (with intake air temperature sensor) (Bank 2) |
| 12 | Recirculation valve (Bank 2) |
| 13 | Turbocharger boost sensor (Bank 2) |
| 14 | Cooling fan relay-1 |
| 15 | Cooling fan relay-2 |
| 16 | Electric throttle control actuator (Bank 2) |
| 17 | Ignition coil (with power transistor) and spark plug (Bank 2) |
| 18 | Camshaft position sensor (PHASE) (Bank 2) |
| 19 | Air cut solenoid valve (Bank 2) |
| 20 | Crankshaft position sensor (POS) |
| 21 | Fuel injector (Bank 2) |
| 22 | Knock sensor |
| 23 | Engine oil temperature sensor |
| 24 | Fuel injector (Bank 1) |
| 25 | Engine coolant temperature sensor |
| 26 | A/F sensor 1 (Bank1) |
| 27 | Camshaft position sensor (PHASE) (Bank 1) |
| 28 | Air cut solenoid valve (Bank 1) |
| 29 | Manifold absolute pressure sensor |
| 30 | Ignition coil (with power transistor) and spark plug (Bank 1) |
| 31 | Electric throttle control actuator (Bank 1) |
| 32 | EVAP service port |
| 33 | Turbocharger boost sensor (Bank 1) |
| 34 | IPDM E/R |
| 35 | Air pump cleaner |
| 36 | Air pump |
| 37 | Air pump relay |
