Nissan Frontier D22 (1998-2007) fuse 39 Wiring diagram
This page shows the only wiring diagram for the component.fuse 39, which is found in the car Nissan Frontier D22 (1998-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 39 (1 of 1)
BLK WIRE
BLU WIRE
COMBINATION METER
COMBINATION SWITCH
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUSE 19
FUSE 39
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
IGNITION RELAY
IND WASHER
IPDM E/R (RIGHT REAR OF ENGINE COMPT)
ORG/ WIRE
RED/YEL WIRE
UNIFIED METER CONTROL UNIT
WASHER FLUID LEVEL SWITCH (RIGHT SIDE OF ENGINE COMPT)
WASHER MOTOR (FR-)
WHT/GRN WIRE
Go to component -> Front wiper/washer circuit -> FUSE 39
