Nissan Frontier D22 (1998-2007) clutch inter lock switch wiring diagram
This page shows the only wiring diagram for the component.clutch inter lock switch, which is found in the car Nissan Frontier D22 (1998-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
clutch inter lock switch wiring diagram (1 of 1)
2.5L 4.0L
BATTERY
BATTERY CURRENT SENSOR (FRONT OF ENGINE COMPT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
CLUTCH INTER LOCK SWITCH
CPU IGN SW GND (SIG) GND (PWR)
FUSE
FUSE, FUSIBLE LINK BOX (RIGHT SIDE OF ENGINE COMPT)
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK J
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INHIBIT
LOCK OFF
NCA WIRE
RED WIRE
STARTER MOTOR
STARTER RELAY
WHT WIRE
WHT/GRN WIRE
Go to component -> Starting circuit, m/t without clutch interlock -> CLUTCH INTER LOCK SWITCH
