System Description
The starter motor plunger closes and provides a closed circuit between the battery and the starter motor. The starter motor is grounded to the cylinder block. With power and ground supplied, the starter motor operates.
Scheme 1
Component Description
| Component part | Description |
|---|---|
| TCM | TCM supplies power to the starter relay inside the IPDM E/R when the selector lever is shifted to the P or N position. |
| BCM | BCM sends a starter request signal to the CPU of the IPDM E/R over the CAN communication lines. |
| IPDM E/R | CPU inside IPDM E/R operates the starter relay at the request of the BCM over the CAN communication lines. |
| Starter motor | The starter motor plunger closes and the motor is supplied with battery power, which in turn cranks the engine, when the "S" terminal is supplied with electric power. |
COMPONENT DESCRIPTION
Description
Terminal "2" (B) is constantly supplied with battery power.
Terminal "1" (S) is the power supply for the starter motor magnetic switch. Terminal 1 is supplied with power when the ignition switch is turned to the START position while the selector lever is in the P or N position.
