APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
| Diagnosis mode | Function Description |
|---|---|
| WORK SUPPORT | Changes the setting for each system function. |
| SELF-DIAG RESULTS | Displays the diagnosis results judged by BCM. Refer to " DTC INDEX ". |
| CAN DIAG SUPPORT MNTR | Monitors the reception status of CAN communication viewed from BCM. |
| DATA MONITOR | The BCM input/output signals are displayed. |
| ACTIVE TEST | The signals used to activate each device are forcibly supplied from BCM. |
| ECU IDENTIFICATION | The BCM part number is displayed. |
| CONFIGURATION | Enables to read and save the vehicle specification. Enables to write the vehicle specification when replacing BCM. |
CONSULT-III FUNCTION CHART
SYSTEM APPLICATION
BCM can perform the following functions for each system.
Note. It can perform the diagnosis modes except the following for all sub system selection items.
| System | Sub system selection item | Diagnosis mode | ||
|---|---|---|---|---|
| WORK SUPPORT | DATA MONITOR | ACTIVE TEST | ||
| BCM | BCM | X | ||
| Door lock | DOOR LOCK | X | X | X |
| Rear window defogger | REAR DEFOGGER | X | ||
| Warning chime | BUZZER | X | X | |
| Interior room lamp timer | INT LAMP | X | X | X |
| Remote keyless entry system (1) | MULTI REMOTE ENT | X | X | X |
| Exterior lamp | HEAD LAMP | X | X | X |
| Wiper and washer | WIPER | X | X | X |
| Turn signal and hazard warning lamps | FLASHER | X | X | |
| Air conditioner | AIR CONDITIONER | X | ||
| Intelligent Key system (2) | INTELLIGENT KEY | X | ||
| Combination switch | COMB SW | X | ||
| Immobilizer | IMMU | X | X | |
| Interior room lamp battery saver | BATTERY SAVER | X | X | X |
| Back door open | TRUNK | X | X | |
| RAP (retained accessory power) | RETAINED PWR | X | X | X |
| Signal buffer system | SIGNAL BUFFER | X | X | |
| TPMS (tire pressure monitoring system) | AIR PRESSURE MONITOR | X | X | X |
| Vehicle security system | PANIC ALARM | X | ||
| (1) With remote keyless entry system (2) With Intelligent Key | ||||
| (1) | With remote keyless entry system |
| (2) | With Intelligent Key |
SYSTEM APPLICATION REFERENCE
Scheme 19
| Work Item | Setting item | Setting | |
|---|---|---|---|
| SET I/L D-UNLCK INTCON | ON (1) | With the interior room lamp timer function | |
| OFF | Without the interior room lamp timer function | ||
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 2 (1) | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 2 | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 (1) | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| (1) Initial setting | |||
| (1) | Initial setting |
