Scheme 71
System Description
IPDM E/R activates the internal control circuit to perform the relay ON-OFF control according to the input signals from various sensors and the request signals received from control units via CAN communication.
| CAUTION | IPDM E/R integrated relays cannot be removed. |
| Control relay | Input/output | Transmit unit | Control part | Reference information |
|---|---|---|---|---|
| Front fog lamp relay | Front fog lamp request signal | BCM (CAN) | Front fog lamps | FRONT FOG LAMP CIRCUIT |
| Headlamp high relay Headlamp low relay | High beam request signal Low beam request signal | BCM (CAN) | Headlamp high Headlamp low | HEADLAMP (HI) CIRCUIT HEADLAMP (LO) CIRCUIT |
| Tail lamp relay | Position light request signal | BCM (CAN) | Parking lamps License plate lamps Tail lamps Trailer tow relay Illumination system | PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON |
| Front wiper relay Front wiper high relay | Front wiper request signal | BCM (CAN) | Front wiper motor | FUNCTION DIAGNOSIS |
| Rear window defogger relay | Rear window defogger request signal | BCM (CAN) | Rear window defogger | FUNCTION DIAGNOSIS |
| A/C relay | A/C request signal | BCM (CAN) ECM (CAN) | A/C compressor | AUTOMATIC AIR CONDITIONER SYSTEM |
| Starter relay | Ignition switch START signal | TCM | Starter motor | FUNCTION DIAGNOSIS |
| Cooling fan relay | Cooling fan request signal | ECM (CAN) | Cooling fan relay | COOLING FAN CONTROL |
| Heated mirror relay | Heated mirror request signal | BCM (CAN) | Door mirrors | FUNCTION DIAGNOSIS |
| ECM relay | ECM relay control signal | ECM (CAN) | ECM relay | MULTIPORT FUEL INJECTION SYSTEM |
| Throttle control motor relay | Throttle control motor control signal | ECM (CAN) | Throttle control motor relay | MULTIPORT FUEL INJECTION SYSTEM |
| Fuel pump relay | Fuel pump request signal | ECM (CAN) | Fuel pump | MULTIPORT FUEL INJECTION SYSTEM |
| Ignition relay | Ignition switch ON signal | Ignition switch | Ignition relay | ELECTRIC IGNITION SYSTEM |
INPUT/OUTPUT SIGNALS REFERENCE CHART
Scheme 72
Scheme 73
IPDM E/R reads the status of the oil pressure switch and transmits the oil pressure switch signal to BCM via CAN communication. Refer to " SYSTEM DESCRIPTION ".
Scheme 74
WAKE-UP OPERATION
- IPDM E/R changes from the low power consumption mode to the normal mode when it receives a sleep wake-up signal (wake up) from BCM or any of the following conditions is fulfilled. In addition, it transmits a sleep-ready signal (not-ready) to BCM via CAN communication to report the CAN communication start. Ignition switch ON An output request is received from a control unit via CAN communication.
Scheme 75
Description
Refer to " SYSTEM DESCRIPTION ".
- PDS (POWER DISTRIBUTION SYSTEM) is the system that BCM controls with the operation of the ignition switch and performs the power distribution to each power circuit.
- If equipped with Intelligent Key, the ignition switch can be operated when Intelligent Key is in the detection area of the interior antenna.
- The ignition switch operation is input to BCM as a signal. BCM changes the power supply position according to the status and operates the ignition relay (inside IPDM E/R) to supply power to each power circuit.
Scheme 76
Component Description
| BCM | Reference |
|---|---|
| IPDM E/R | SYSTEM DESCRIPTION |
| Ignition relay (in IPDM E/R) | SYSTEM DESCRIPTION |
| Park/neutral position switch | DTC P0705 PARK/NEUTRAL POSITION SWITCH |
COMPONENT DESCRIPTION CHART
Refer to " SYSTEM DESCRIPTION ".
