Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SRS AIRBAG - ARMADA article and SEAT BELTS - ARMADA article.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYSTEM). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

Precaution for Power Generation Variable Voltage Control System

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

SPECIAL SERVICE TOOL SPECIFICATION Tool number (Kent Moore No.) Tool name Description - (-) Model GR-8 Multi-tasking Battery Diagnostic Station Tests Batteries, starting and charging system. For operating instructions, refer to diagnostic station instruction information

Scheme 8

Commercial Service Tool

COMMERCIAL SERVICE TOOL SPECIFICATION Tool name Description Power tool Loosening bolts and nuts

Scheme 9

DETAILED FLOW

Note. To ensure a complete and thorough diagnosis, the battery, starter motor and generator test segments must be done as a set from start to finish.

1. DIAGNOSIS WITH MULTI-TASKING BATTERY DIAGNOSTIC STATION Perform the starting system test with multi-tasking battery diagnostic station. For details and operating instructions, refer to diagnostic station instruction information. Test result CRANKING NORMAL: GO TO 2 . LOW VOLTAGE: GO TO 5 . CHARGE BATTERY: Perform the slow battery charging procedure. (Initial rate of charge is 10A for 12 hours.) Perform battery test again. Refer to diagnostic station instruction information. REPLACE BATTERY: Before replacing battery, clean the battery cable clamps and battery posts. Perform battery test again. Refer to diagnostic station instruction information. If second test result is "REPLACE BATTERY", then do so. Perform battery test again to confirm repair.
2. CRANKING CHECK Check that the starter motor operates properly. Does the engine crank normally? YES: GO TO 3 . NO: GO TO 4 .
3. ENGINE START CHECK Check that the engine starts. Does the engine start? YES: Starter motor is OK. Inspection end. NO: Perform further diagnosis of engine mechanical or engine control system. Refer to «ENGINE MECHANICAL - ARMADA»(ref-382166) article, and «ENGINE CONTROL SYSTEM (VK56DE) - ARMADA»(ref-382156) article . Once resolved, perform battery test again.
4. STARTER MOTOR ACTIVATION Check that the starter motor operates. Does the starter motor turn? YES: Check ring gear and starter motor drive pinion. Once resolved, perform battery test again. NO: GO TO 7 .
5. COMPARISON BETWEEN ENGINE COOLANT AND CRANKING VOLTAGE Compare the engine coolant temperature and verify the cranking voltage is within specification. Minimum Specification of Cranking Voltage Referencing Coolant Temperature ENGINE COOLANT TEMPERATURE SPECIFICATION Engine coolant temperature [°C (°F)] Voltage [V] -30 to -20 (-22 to -4) 8.6 -19 to -10 (-2 to 14) 9.1 -9 to 0 (16 to 32) 9.5 More than 1 (More than 34) 9.9 Is the voltage less than the specified value? YES: GO TO 7 . NO: GO TO 6 .
6. STARTER OPERATION Check the starter operation. Does the starter motor turn smoothly? YES: Starter motor is OK. Inspection End. NO: GO TO 7 .
7. "B" TERMINAL CIRCUIT INSPECTION Check "B" terminal circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-382200-S27250142912011011400000) ". Is "B" terminal circuit normal? YES: GO TO 8 . NO: Repair as needed.
8. "S" CONNECTOR CIRCUIT INSPECTION Check "S" connector circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-382200-S13012132242011011400000) ". Is "S" connector circuit normal? YES: GO TO 9 . NO: Repair as needed.
9. ENGINE ROTATION STATUS Check that the engine can be rotated by hand. Does the engine turn freely by hand? YES: Replace starter motor. Refer to " «REMOVAL AND INSTALLATION»(ref-382200-S31916503662011011400000) ". NO: Perform further diagnosis of engine mechanical or powertrain mechanism. Refer to «ENGINE MECHANICAL - ARMADA»(ref-382166) article or «AUTOMATIC TRANSMISSION - ARMADA»(ref-382157) article . Once resolved, perform battery test again. Refer to diagnostic station instruction information.

Scheme 10

Starter

STARTER SPECIFICATION
