Seat Belts: Overview Nissan Armada I рестайлинг

OPERATION PROCEDURE

1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-III.

Scheme 1

Scheme 2

Scheme 3

1. Disconnect both battery terminals, then wait at least three minutes.
2. Remove the center pillar lower finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S27884325092011011400000) ".
3. Remove the retractor anchor bolt, retractor bolt upper, then remove the retractor and belt assembly. On RH side, disconnect the seat belt tension sensor.
4. Disconnect the seat belt pre-tensioner electrical connector. CAUTION: For removing pre-tensioner connector, insert a thin screwdriver (1) wrapped in tape (3) into the notch. Lift the locking tab to unlock (2), then remove the connector. Install the pre-tensioner connector with the locking tab raised, then push the locking tab into the connector to lock (4).
