Interior Lighting System: Removal & Installation Nissan Armada I рестайлинг

Removal

The vanity mirror lamp is replaced as part of the sunvisor assembly. Refer to " REMOVAL AND INSTALLATION ".

Installation

Installation is in the reverse order of removal.

Bulb Replacement

Scheme 58

1. Using a suitable tool (A), release the tabs and remove the vanity mirror lamp lens (1). o: Pawl
2. Release one side of the bulb (2) from the tab, then pull straight out to remove. Vanity mirror lamp bulb : 12V - 1.8W CAUTION: Wrap a cloth around tool to protect the housing and lens.

1. Remove instrument lower panel RH and glove box. Refer to " «REMOVAL AND INSTALLATION»(ref-382164-S18040903462011011400000) ".
2. Rotate glove box lamp socket and rotate counterclockwise to release from steering member.

Installation is in the reverse order of removal.

Scheme 59

1. Remove instrument lower panel RH and glove box. Refer to " «REMOVAL AND INSTALLATION»(ref-382164-S18040903462011011400000) ".
2. Pull bulb (2) straight out from glove box lamp socket (1) to remove. Glove box lamp bulb : 12V - 3.4W

Scheme 60

1. Insert a suitable tool between door finisher and step lamp lens/socket to release the pawls.
2. Disconnect the step lamp connector, then remove step lamp.

Installation is in the reverse order of removal.

Bulb Replacement

1. Remove the step lamp lens/socket.
2. Pull the bulb straight out to remove. Step lamp bulb : 12V - 3.8W

Scheme 61

1. Remove overhead console. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S34622778052011011400000) ".
2. Remove personal lamp screws (3).
3. Disconnect personal lamp electrical connectors (1), then remove personal lamps (2) from overhead console.

Installation is in the reverse order of removal.

Scheme 62

1. Using a suitable tool (A), release the pawls and remove personal lamp lens (1). o: Pawl
2. Pull bulb (2) straight out to remove. Personal lamp bulb : 12V - 6W CAUTION: Wrap a cloth around tool to protect the housing and lens.

Rotate foot lamp socket (3) counterclockwise from bracket.

Bulb shield (1)

Bulb (2)

Scheme 63

Installation is in the reverse order of removal.

1. Release the pawls and remove bulb shield from bracket (1).
2. Pull bulb (2) straight out from footwell lamp socket (3) to remove. Footwell lamp bulb : 12V - 3.4W

The illumination control switch (1) is replaced as a part of the combination meter assembly. Refer to " REMOVAL AND INSTALLATION ".

Scheme 64

Installation is in the reverse order of removal.

Scheme 65

1. Using a suitable tool (A), release the pawls and remove the cargo lamp lens (1). o: Pawl
2. Remove cargo lamp screws (2).
3. Disconnect the connector, then remove cargo lamp.

Installation is in the reverse order of removal.

Scheme 66

1. Using a suitable tool, release the pawls and remove the cargo lamp lens.
2. Release the cargo lamp bulb retainers (1), then pull bulb (2) straight out to remove. Cargo lamp bulb : 12V - 8W

Scheme 67

1. Remove overhead console. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S34622778052011011400000) ".
2. Rotate console illumination lamp bulb (1) counterclockwise, then pull straight out away from map lamp assembly (2) to remove.
