The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in SUPPLEMENTAL RESTRAINT SYSTEM and SEAT BELTS .
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see SUPPLEMENTAL RESTRAINT SYSTEM . Do not use electrical test equipment on any circuit related to the SRS unless instructed to. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
MANUAL OPERATION
The driving position [seat position, pedal position (accelerator, brake) and door mirror position] can be adjusted with the power seat switch LH or pedal adjusting switch or door mirror remote control switch.
Note. The door mirrors can be manually operated with the ignition switch turned to ACC or ON. Only when A/T shift lever is in P position, adjusting pedal operates (except when ignition switch turned to OFF). If A/T device (detent switch) error is detected, manual adjustable pedal operation cannot be performed when ignition switch turns ON.
Scheme 1
Note. Disconnecting the battery erases the stored memory. After connecting the battery, insert the key into the ignition cylinder and turn the front door switch LH ON (open)-->OFF (close)-->ON (open), the Entry/Exiting function becomes possible. After Exiting operation is carried out, return operation can be operated.
Scheme 2
Note. During automatic operation, if the ignition switch is turned ON-->START, the automatic operation is suspended. When the ignition switch returns to ON, it resumes.
SYSTEM DESCRIPTION
- The system automatically moves the front seat to facilitate entry/exit to/from the vehicle. The driver seat control unit can also store the optimum driving positions (front seat, pedal position and door mirror position) for 2 people. If the front seat is changed, one-touch operation allows changing to the other driving position.
- The settings (ON/OFF) of the automatic sliding seat (Entry/Exiting operation) at entry/exit can be changed as desired, using the display unit in the center of the instrument panel. The set content is transmitted by CAN communication, from display unit (without NAVI) or display control unit (with NAVI) to driver seat control unit.
- Using CONSULT-II, the seat slide amount at entry/exit setting can be changed.
MEMORY OPERATION
Selecting the memorized position.
Scheme 3
Note. The front seat position and pedal adjustment functions (see the following REFERENCE CHART ) operate simultaneously in the order of priority.
| Priority | Function | Priority | Function |
|---|---|---|---|
| 1 | Seat sliding, (door mirror LH/RH) (1) | 4 | Seat lifter-FR |
| 2 | Pedal | 5 | Seat lifter-RR |
| 3 | Seat reclining | ||
| (1) In conjunction with sliding the seat, the door mirrors are positioned. | |||
| (1) | In conjunction with sliding the seat, the door mirrors are positioned. |
REFERENCE CHART
ENTRY OPERATION
When the seat is in the exiting positions, the following operation moves the seat to the previous position before the exiting operation.
Scheme 4
EXITING OPERATION
At Entry/Exiting, the seat is automatically moved to the exiting position.
Scheme 5
Scheme 6
- The system performs memory operation, exiting operation and return operation by pressing keyfob unlock button.
Note. If Entry/Exiting operation is cancelled, the system performs memory operation only. If ignition switch turns ON in the middle of memory operation, the system does not perform exiting operation after memory operation. If ignition switch turns ON in the middle of exiting operation, entry operation starts at that time.
CAN COMMUNICATION SYSTEM DESCRIPTION
Refer to CAN COMMUNICATION .
