FRONT SIDE MARKER LAMP Nissan Armada I

Lighting System 1 illustration ~197 words

FRONT SIDE MARKER LAMP

Note. Reach through wheel opening for access.

  1. Turn the bulb socket counterclockwise to unlock it.
  2. Pull the bulb to remove it from the socket.

Installation is in the reverse order of removal.

CAUTIONAfter installing the bulb, be sure to install the bulb socket securely to ensure watertightness.

Scheme 175

Scheme 175: REMOVAL
Scheme 175: REMOVAL
  1. Remove the grille. Refer to «REMOVAL AND INSTALLATION»(ref-233303-S08096742232006052500000) .
  2. Remove the front bumper filler panel.
  3. Disconnect the connector.
  4. Remove the 4 headlamp mounting bolts.

Power is supplied at all times

  1. through 50A fusible link (letter f, located in the fuse and fusible link box)
  2. to BCM terminal 70, and
  3. through 10A fuse [No. 19, located in the fuse block (J/B)]
  4. to combination meter terminal 8, and
  5. through 10A fuse [No. 45, located in the IPDM E/R (intelligent power distribution module engine room)]
  6. to daytime light relay terminals 2 and 5.

When the ignition switch is in ON or START position, power is supplied

  1. through 10A fuse (No. 59, located in the fuse and relay box)
  2. to BCM terminal 38, and
  3. through 10A fuse [No. 14, located in the fuse block (J/B)]
  4. to combination meter terminal 24.

Ground is supplied

  1. to BCM terminal 67 and
  2. to combination meter terminal 17
  3. through grounds M57, M61 and M79.
