Front Final Drive: Removal & Installation Nissan Armada I

REMOVAL

1. Remove front final drive. Refer to «REMOVAL»(ref-233279-S27019604112006052500000) .
2. Drain gear oil. Refer to «CHANGING FINAL DRIVE OIL»(ref-233319-S21997828612006052500000) .
3. Remove rear cover.

Scheme 14

Scheme 15

1. Apply 3.2 mm (0.126 in) bead of sealant to the rear cover. Use Genuine Silicone RTV sealant or equivalent. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-233237-S23907478682006052500000) .
2. Install rear cover and tighten rear cover bolts in the order as shown in «COMPONENTS»(ref-233281-S19583054682006052500000) .
3. Fill final drive with recommended gear oil. Refer to «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-233237-S23907478682006052500000) .
4. Install front final drive. Refer to «INSTALLATION»(ref-233279-S24913720712006052500000) .

Scheme 16

Scheme 17

1. Remove front propeller shaft. Refer to «REMOVAL»(ref-233278-S23417333772006052500000) . CAUTION: Be careful not to damage spline, sleeve yoke and front oil seal when removing propeller shaft.
2. Separate LH and RH drive shafts from front final drive. Refer to «REMOVAL»(ref-233279-S27019604112006052500000) .
3. Remove front cross member.
4. Disconnect the vent hose.
5. Support the front final drive with suitable jack and remove the front final drive bolts. Carefully remove front final drive.

Scheme 18

1. Install front final drive assembly. Front final drive bolts: 182.5 N.m (19 Kg-m, 135 ft-lb)
2. Connect the vent hose.
3. Install the front cross member.
4. Install LH and RH drive shaft. Refer to «INSTALLATION»(ref-233279-S24913720712006052500000) .
5. Install front propeller shaft. Refer to «INSTALLATION»(ref-233278-S13581978012006052500000) .

Scheme 19
