Automatic Transmission: Removal & Installation Nissan Armada I

REMOVAL

1. Remove A/T finisher. Refer to «A/T FINISHER»(ref-233304-S10930176492006052500000) .
2. Disconnect selector control cable.
3. Disconnect A/T device harness connector.
4. Remove control device assembly.

INSTALLATION

Installation is in reverse order of removal. Be careful of the following

1. After installation is completed, adjust and check A/T position.

Scheme 152

1. Loosen nut of control cable.
2. Place PNP switch and selector lever in "P" position.
3. After pushing the control cable in the direction shown with a force of 9.8 N.m (1kg-m, 2.2 lb-ft), release it. This is in the natural state, tighten control cable nut to specifications. Control cable nut: 14.5 N.m (1.5 kg-m, 11 ft-lb)

Scheme 153

1. Place selector lever in "P" position, and turn ignition switch ON (engine stop).
2. Make sure selector lever can be shifted to other than "P" position when brake pedal is depressed. Also make sure selector lever can be shifted from "P" position only when brake pedal is depressed.
3. Move the selector lever and check for excessive effort, sticking, noise or rattle.
4. Confirm the selector lever stops at each position with the feel of engagement when it is moved through all the positions. Check whether or not the actual position the selector lever is in matches the position shown by the shift position indicator and the transmission body.
5. The method of operating the lever to individual positions correctly should be as shown.
6. Confirm the back-up lamps illuminate only when lever is placed in the "R" position. Confirm the back-up lamps does not illuminate when selector lever is pushed against "R" position in the "P" or "N" position.
7. Confirm the engine can only be started with the selector lever in the "P" and "N" positions.
8. Make sure transmission is locked completely in "P" position.

Scheme 154

Scheme 155

1. Drain A/T fluid, refer to «CHANGING A/T FLUID»(ref-233319-S28143630952006052500000) .
2. Remove oil pan and gasket.
3. Check foreign materials in oil pan to help determine cause of malfunction. If the A/T fluid is very dark, has some burned smell, or contains foreign particles, friction material (clutches, band) may need replacement. A tacky film that will not wipe clean indicates varnish build up. Varnish can cause valves, servo, and clutches to stick and can inhibit pump pressure. CAUTION: If friction material is detected, flush the transmission cooler after repair, refer to «A/T FLUID COOLER CLEANING PROCEDURE»(ref-233274-S20884774452006052500000) .
4. Remove magnets from oil pan.

Scheme 156

Scheme 157

Scheme 158

1. Install the oil pan magnets as shown.
2. Install the oil pan and new oil pan gasket. CAUTION: Be sure the oil pan drain plug is located to the rear of the transmission assembly. Before installing oil pan bolts, remove any traces of old sealant from the sealing surfaces and threaded holes. Do not reuse old gasket, replace with a new one. Always replace the oil pan bolts as they are self-sealing. Partially install the oil pan bolts in a criss-cross pattern to prevent dislocation of the gasket.
3. Tighten oil pan bolts in numerical order as shown. Oil pan bolts: 7.9 N.m (0.81 kg-m, 70 in-lb)
4. Install drain plug in oil pan. CAUTION: Do not reuse old drain plug gasket replace with a new one. Drain plug: 34 N.m (3.5 kg-m, 25 ft-lb)
5. Refill the transmission assembly with fluid. Refer to «CHANGING A/T FLUID»(ref-233319-S28143630952006052500000) .

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

1. Disconnect negative battery terminal
2. Drain ATF through drain plug.
3. Disconnect A/T assembly harness connector.
4. Remove snap ring from A/T assembly harness connector.
5. Push A/T assembly harness connector. CAUTION: Be careful not to damage connector.
6. Remove oil pan and oil pan gasket, refer to «Removal»(ref-233274-S34849123152006052500000) .
7. Disconnect A/T fluid temperature sensor 2 connector. CAUTION: Be careful not to damage connector.
8. Straighten terminal clip to free terminal cord assembly A/T fluid temperature sensor 2 harness.
9. Disconnect revolution sensor connector. CAUTION: Be careful not to damage connector.
10. Straighten terminal clips to free revolution sensor harness.
11. Remove bolts A, B and C from control valve with TCM. BOLTS SPECIFICATIONS Bolt symbol Length mm (in) Number of bolts A 42(1.65) 5 B 55(2.17) 6 C 40(1.57) 1
12. Remove control valve with TCM from transmission case. CAUTION: When removing, be careful with the manual valve notch and manual plate height. Remove it vertically.
13. Remove A/T fluid temperature sensor 2 with bracket from control valve with TCM.
14. Remove bracket from A/T fluid temperature sensor 2.
15. Remove O-ring from A/T assembly harness connector.
16. Disconnect TCM connectors. CAUTION: Be careful not to damage connectors.
17. Remove A/T assembly harness connector from control valve with TCM using flat-bladed screwdriver.
18. Disconnect TCM connector and park/neutral position switch connector CAUTION: Be careful not to damage connectors.

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

1. Connect TCM connector and park/neutral position switch connector.
2. Install A/T assembly harness connector to control valve with TCM.
3. Connect TCM connector.
4. Install new O-ring in A/T assembly harness connector. NOTE: Do not reuse O-ring. Apply ATF to O-ring.
5. Install A/T fluid temperature sensor 2 to bracket.
6. Install A/T fluid temperature sensor 2 (with bracket) in control valve with TCM. Tighten A/T fluid temperature sensor 2 bolt to the specified torque. Refer to «COMPONENTS»(ref-233274-S04374539092006091900000) . CAUTION: Adjust bolt hole of bracket to bolt hole of control valve with TCM.
7. Install control valve with TCM in transmission case. CAUTION: Make sure that turbine revolution sensor securely installs turbine revolution sensor hole. Hang down revolution sensor harness toward outside so as not to disturb installation of control valve with TCM. Adjust A/T assembly harness connector of control valve with TCM to terminal hole of transmission case. Assemble it so that manual valve cutout is engaged with manual plate projection.
8. Install bolts A, B and C in control valve with TCM. BOLTS SPECIFICATIONS Bolt symbol Length mm (in) Number of bolts A 42 (1.65) 5 B 55 (2.17) 6 C 40 (1.57) 1
9. Tighten bolt 1, 2 and 3 temporarily to prevent dislocation. After that tighten them in order (1 --> 2 --> 3), and then tighten other bolts.
10. Tighten control valve with TCM bolts to the specified torque. Refer to «COMPONENTS»(ref-233274-S04374539092006091900000) .
11. Connect A/T fluid temperature sensor 2 connector.
12. Securely fasten terminal cord assembly and A/T fluid temperature sensor 2 harness with terminal clips.
13. Connect revolution sensor connector.
14. Securely fasten revolution sensor harness with terminal clips.
15. Install oil pan to transmission case, refer to «INSTALLATION»(ref-233274-S19658178122006052500000) .
16. Pull up A/T assembly harness connector. CAUTION: Be careful not to damage connector.
17. Install snap ring to A/T assembly harness connector.
18. Connect A/T assembly harness connector.
19. Pour ATF into transmission assembly. Refer to «CHANGING A/T FLUID»(ref-233319-S28143630952006052500000) .
20. Connect the negative battery terminal

Scheme 190

Scheme 191

Scheme 192

Scheme 193

1. Disconnect negative battery terminal
2. Remove oil pan and oil pan gasket, refer to «REMOVAL»(ref-233274-S34849123152006052500000) .
3. Disconnect A/T fluid temperature sensor 2 connector. CAUTION: Be careful not to damage connector.
4. Straighten terminal clip to free A/T fluid temperature sensor 2 harness.
5. Remove A/T fluid temperature sensor 2 with bracket from control valve with TCM.
6. Remove bracket from A/T fluid temperature sensor 2.

Scheme 194

Scheme 195

Scheme 196

Scheme 197

1. Install A/T fluid temperature sensor 2 to bracket.
2. Install A/T fluid temperature sensor 2 (with bracket) in control valve with TCM. Tighten A/T fluid temperature sensor 2 mounting bolt to the specified torque. Refer to «COMPONENTS»(ref-233274-S04374539092006091900000) . CAUTION: Adjust bolt hole of bracket to bolt hole of control valve with TCM.
3. Connect A/T fluid temperature sensor 2 connector.
4. Securely fasten A/T temperature sensor 2 harness with terminal clip.
5. Install oil pan to transmission case, refer to «INSTALLATION»(ref-233274-S19658178122006052500000) .
6. Connect the negative battery terminal

Scheme 198

1. Remove rear propeller shaft. Refer to «REMOVAL»(ref-233278-S18609968022006052500000) .
2. Remove transfer from transmission (4WD models). Refer to «REMOVAL»(ref-233277-S05296131472006052500000) .
3. Remove rear oil seal using a flat-bladed screwdriver or suitable tool. CAUTION: Be careful not to scratch rear extension assembly (2WD models) or adapter case assembly (4WD models).

Scheme 199

1. Install new rear oil seal into the extension case (2WD models) or adapter case (4WD models) until it is flush with component face, using Tool or suitable drift. CAUTION: Apply ATF to rear oil seal. Do not reuse rear oil seal.
2. Install transfer to transmission (4WD models). Refer to «INSTALLATION»(ref-233277-S33909042252006052500000) .
3. Install rear propeller shaft. Refer to «INSTALLATION»(ref-233278-S08330633252006052500000)

Scheme 200

Scheme 201

Scheme 202

1. Disconnect the negative battery terminal.
2. Remove engine cover.
3. Remove A/T fluid indicator gauge.
4. Remove engine under cover with power tool. Refer to «REMOVAL»(ref-233272-S41515308372006052500000)
5. Remove exhaust front tube and center muffler with power tool. Refer to.
6. Remove rear propeller shaft. Refer to «REMOVAL»(ref-233278-S18609968022006052500000) .
7. Remove A/T control cable. Refer to «REMOVAL»(ref-233274-S28489523562006052500000) .
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Remove fluid cooler tube.
10. Remove dust cover from converter housing part.
11. Turn crankshaft, and remove the four tightening bolts for drive plate and torque converter. CAUTION: When turning crankshaft, turn it clockwise as viewed from the front of the engine.
12. Support A/T assembly with a transmission jack. CAUTION: When setting the transmission jack, be careful not to allow it to collide against the drain plug.
13. Remove cross member with power tool.
14. Remove air breather hose. Refer to «REMOVAL AND INSTALLATION»(ref-233274-S05708354702006052500000) .
15. Disconnect A/T assembly connector.
16. Remove A/T fluid indicator pipe from A/T assembly.
17. Plug up openings such as the A/T fluid indicator pipe hole, etc.
18. Remove the A/T assembly to engine bolts with power tool.
19. Remove A/T assembly from vehicle using Tool and a transmission jack. CAUTION: Secure torque converter to prevent it from dropping. Secure A/T assembly to a transmission jack.

Installation of the remaining components is in the reverse order of the removal, while paying attention to the following

Scheme 203

1. When installing transmission to the engine, attach the bolts as shown. Transmission to engine bolts: 113 N.m (12 kg-m, 83 ft-lb) NOTE: No. 2 bolt also secures air breather vent.
2. Align the positions of bolts for drive plate with those of the torque converter, and temporarily tighten the bolts. Then, tighten the bolts with the specified torque.

Scheme 204

1. Install crankshaft position sensor (POS).
2. After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to «CHECKING A/T FLUID»(ref-233319-S17814459722006052500000) , «CHECKING OF A/T POSITION»(ref-233274-S04141549412006052500000) and «ADJUSTMENT OF A/T POSITION»(ref-233274-S06355749752006052500000) .

Scheme 205

Scheme 206

Scheme 207

Scheme 208

1. Disconnect the negative battery terminal.
2. Remove engine cover with power tool.
3. Remove A/T fluid indicator.
4. Remove engine under cover with power tool.
5. Remove exhaust front tube and center muffler with power tool. Refer to «REMOVAL»(ref-233272-S41515308372006052500000) .
6. Remove propeller shaft. Refer to «REMOVAL»(ref-233278-S23417333772006052500000) and «REMOVAL»(ref-233278-S18609968022006052500000) .
7. Remove A/T control cable. Refer to «REMOVAL»(ref-233274-S28489523562006052500000) .
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Disconnect A/T fluid cooler tube from A/T assembly.
10. Remove dust cover from converter housing part.
11. Turn crankshaft, and remove the four bolts for drive plate and torque converter. CAUTION: When turning crankshaft, turn it clockwise as viewed from the front of the engine.
12. Support A/T assembly with a transmission jack. CAUTION: When setting the transmission jack, be careful not to allow it to collide against the drain plug.
13. Remove cross member with power tool.
14. Tilt the transmission slightly to keep the clearance between body and transmission, and then disconnect air breather hose from A/T fluid indicator pipe. Refer to «REMOVAL»(ref-233274-S04650071492006052500000) .
15. Disconnect A/T assembly connector and transfer unit connector.
16. Remove A/T fluid indicator pipe.
17. Plug up openings such as the fluid charging pipe hole, etc.
18. Remove A/T assembly to engine bolts with power tool.
19. Remove A/T assembly with transfer from vehicle, using Tool. Tool number: - (J-47002) CAUTION: Secure torque converter to prevent it from dropping. Secure A/T assembly to a transmission jack. NOTE: The actual special service tool may differ from tool shown.
20. Remove transfer from A/T assembly. Refer to «REMOVAL»(ref-233277-S05296131472006052500000) .

Scheme 209

1. After inserting a torque converter to a transmission, be sure to check dimension A to ensure it is within the reference value limit. Dimension A: 24.0 mm (0.94 in) or more

Installation of the remaining components is in the reverse order of removal, while paying attention to the following

Scheme 210

1. When installing transmission to the engine, attach the bolts as shown. Transmission to engine: 113 N.m (12 kg-m, 83 ft-lb) bolts NOTE: No. 2 bolt also secures air breather vent.
2. Align the positions of bolts for drive plate with those of the torque converter, and temporarily tighten the bolts. Then, tighten the bolts with the specified torque.

Scheme 211

1. Install crankshaft position sensor (POS).
2. After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to «CHECKING A/T FLUID»(ref-233319-S17814459722006052500000) , «CHECKING OF A/T POSITION»(ref-233274-S04141549412006052500000) and «ADJUSTMENT OF A/T POSITION»(ref-233274-S06355749752006052500000) .

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219
