AV SWITCH SELF-DIAGNOSIS FUNCTION Nissan Armada I

Audio Visual System, Navigation System & Telephone System: Diagnosis 2 illustrations ~176 words

AV SWITCH SELF-DIAGNOSIS FUNCTION

It can check ON/OFF operation of each switch in the AV switch and diagnose the input signals from the steering switch.

Scheme 21

Scheme 21: STARTING THE SELF-DIAGNOSIS MODE (WITHOUT NAVI)
Scheme 21: STARTING THE SELF-DIAGNOSIS MODE (WITHOUT NAVI)
  1. Turn ignition switch from OFF to ACC.
  2. Press and hold the "PAUSE/MUTE" switch and turn the volume control dial clockwise or counterclockwise for 30 clicks or more. Then the self-diagnosis operates. A single beep indicates self-diagnosis mode is active.
  3. Initially, all display segments will be illuminated.
  4. Press each switch. When each switch is pressed, its name and communication code will be displayed. NOTE: CD player LOAD and EJECT buttons are not included in this test and will not change the display when pressed.

Scheme 22

Scheme 22: STARTING THE SELF-DIAGNOSIS MODE (WITH NAVI)
Scheme 22: STARTING THE SELF-DIAGNOSIS MODE (WITH NAVI)
  1. Turn ignition switch from OFF to ACC.
  2. Within 10 seconds press and hold the switches "PAUSE/MUTE" and "PREV" simultaneously for 3 seconds. Then the self-diagnosis operates. A single beep indicates self-diagnosis mode is active.
  3. Press each switch and listen for beep. NOTE: CD player LOAD and EJECT buttons are not included in this test and will not beep when pressed.
