CRANKSHAFT POSITION SENSOR
Note. The crankshaft position sensor is located inside the distributor.
FUEL SYSTEM
| WARNING | Always relieve fuel pressure before disconnecting any fuel injection-related component. DO NOT allow fuel to contact engine or electrical components. |
FUEL SYSTEM PRESSURE RELEASE
- Remove fuel pump fuse No. 3 from fuse/relay panel located under access cover at lower left side of dash. (Scheme 6)
- Start engine and allow to run until fuel is exhausted and engine stalls. Crank engine an additional 2 or 3 times to verify all pressure has dissipated. Turn ignition off. Install fuel pump fuse.
Scheme 6
FUEL PUMP
Note. Fuel pump is located in fuel tank. (Scheme 7) If vehicle is not equipped with a maintenance access cover for fuel pump service, remove fuel tank.
Scheme 7
FUEL RAILS & INJECTORS
Note. For installation referencr, label wiring harness and fuel lines prior to disconnecting. Also note direction of injector electrical connectors for installation reference.
