Steering Control System (Coupe): Other Nissan Altima L33

Steering Control Systems 10 illustrations ~760 words

DETAILED FLOW

  1. COLLECT THE INFORMATION FROM THE CUSTOMER It is also important to clarify customer complaints before inspection. First of all, reproduce symptoms, and understand them fully. Ask customer about his/her complaints carefully. In some cases, it will be necessary to check symptoms by driving vehicle with customer. : GO TO 2.
  2. BASIC INSPECTION Check the power steering fluid leakage and the power steering fluid level. Refer to " «INSPECTION»(ref-592021-S27696726242014010800000) ". Check the drive belt tension. Refer to " «CHECKING DRIVE BELTS»(ref-592016-S23413086692014010800000) ". Check the power steering gear for damages, cracks and oil leakage. Refer to " «INSPECTION»(ref-592021-S27696726242014010800000) ". Check the relief oil pressure. Refer to " «INSPECTION»(ref-592021-S04798475032014010800000) ". : GO TO 3.
  3. TROUBLE DIAGNOSIS FOR SYMPTOM Perform the diagnosis by symptom. Refer to " «DESCRIPTION»(ref-592052-S19112745252014010800000) ". : GO TO 4.
  4. FINAL CHECK Check the input/output standard values for the power steering control unit. Are the power steering control unit input/output values within standard ranges respectively? YES: Inspection End NO: GO TO 2 .

Scheme 26

Scheme 26: CONTROL DIAGRAM
Scheme 26: CONTROL DIAGRAM

Scheme 27

Scheme 27: System Description
Scheme 27: System Description
  1. The EPS system controls the power steering solenoid valve through the power steering control unit.
  2. The valve driving voltage to control the power steering solenoid valve varies according to the vehicle speed.

Scheme 28

Scheme 28: During Parking (When Turning The Steering Wheel To The Right)
Scheme 28: During Parking (When Turning The Steering Wheel To The Right)
  1. Power steering solenoid valve is closed while a vehicle is stopped.
  2. Pinion "1R", "2R" and "3R" are closed depending on steering torque of steering wheel.
  3. Oil pressure "P" in the gear housing assembly is the sum of oil pressures occurred in "2R" and "3R". This results in a light steering force because of high pressure.

Scheme 29

Scheme 29: During High-speed Operation
Scheme 29: During High-speed Operation
  1. Power steering solenoid valve is opened during high-speed operation.
  2. Pinion "1R", "2R" and "3R" are closed depending on steering torque of steering wheel.
  3. Oil pressure "2R" does not occur because the power steering solenoid valve is on full throttle.
  4. Oil pressure "P" in the gear housing assembly includes only oil pressure occurred in "3R" and results in a heavy steering force.

Scheme 30

Scheme 30: Component Parts Location
Scheme 30: Component Parts Location

PHYSICAL VALUES

Terminal No. Wire color Description Condition Value (Approx.) + - Signal name Input/Output 1 Ground R/Y Power steering solenoid valve voltage Output Vehicle speed: 0 km/h (0 MPH) (Engine is running) 4.4 - 6.6 V Vehicle speed: 100 km/h (62 MPH) 2.5 - 3.7 V 3 Ground G Ignition power supply Input Ignition switch: ON Battery voltage Ignition switch: OFF 0 V 5 Ground LG/W Power steering solenoid valve ground - Always 0 V 6 Ground B Ground - Always 0 V 8 Ground L/B Vehicle speed signal Input Vehicle speed: 40 km/h (25 MPH) CAUTION: Check air pressure of tire under standard condition. 10 Ground V/W Engine speed signal Input Engine speed: At idle (Warm-up condition) Engine speed: Approx. 2, 000 RPM (Warm-up condition)

CAUTIONWhen using circuit tester or oscilloscope to measure voltage for inspection, be sure not to extend forcibly any connector terminals.

Scheme 31

Scheme 31: EPS system
Scheme 31: EPS system
  1. EPS system enters the fail-safe mode (that allows the steering force to be controlled without impairing the drive ability) if any of the input/output signals to/from EPS system (power steering control unit) deviate from the standard. NOTE: The system enters the fail-safe mode if the engine speed remains at 1, 500 RPM or more for over 10 seconds while the vehicle is stopped. This is normal.
  2. The fail-safe function is canceled when a vehicle speed signal of 2 km/h (1.2 MPH) or more is inputted or the key switch is turned OFF--> ON. EPS system restores the normal operation at that time.
FunctionWarning lampDTC No.Detection point (malfunction part)Malfunction part and cause
Fail-safe functionVehicle speed signalEngine speed is 1, 500 RPM or more and there is no vehicle speed signal input for over 10 seconds during vehicle travel. Vehicle speed signal has abruptly dropped from 30 km/h (19 MPH) or more to 2 km/h (1.2 MPH) or less within 1.4 seconds.

Scheme 32

Scheme 32: Wiring Diagram
Scheme 32: Wiring Diagram

Scheme 33

Scheme 33: Connector Terminal Identification
Scheme 33: Connector Terminal Identification

Scheme 34

Scheme 34
Scheme 34

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are buckled or unbuckled.

Information necessary to service the system safely is included in the SRS Airbag and Seat Belts article of this Service Information.

WARNINGTo avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGWhen working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Remove AV control unit or audio unit. Refer to " «REMOVAL AND INSTALLATION»(ref-592053-S33897906232014010800000) " (BASE AUDIO), " «REMOVAL AND INSTALLATION»(ref-592054-S26373563272014010800000) " [BOSE AUDIO W/O NAVIGATION (TYPE A)], " «REMOVAL AND INSTALLATION»(ref-592054-S26373563272014010800000) " [BOSE AUDIO W/O NAVIGATION (TYPE B)] or " «REMOVAL AND INSTALLATION»(ref-592055-S30829901062014010800000) " (BOSE WITH NAVIGATION).
  2. Remove power steering control unit (1).
  3. Disconnect power steering control unit connector.
