INSTALLATION
Installation is in the reverse order of removal.
| CAUTION | Apply Genuine Mirror Adhesive or equivalent to bonding surface of mounting bracket. Refer to " RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS ". |
Scheme 31
Scheme 32
- Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-592057-S30789231392014010800000) ".
- Disconnect the door mirror harness connector.
- Remove the door mirror nuts, and remove the door mirror assembly.
Installation is in the reverse order of removal.
Scheme 33
Scheme 34
Scheme 35
- Turn the mirror glass surface upward.
- Apply a protective tape (A) to mirror housing. Insert a suitable tool (B) into the concave gap between the mirror holder (1) and mirror motor (2) Push up tabs (3) (two locations) on the mirror holder to disengage the lower part of mirror holder, and remove the mirror glass and holder. NOTE: When pushing up tabs (3), do not forcefully push up only one concave position but try to push up two concave positions.
- Remove the mirror glass and holder (1) from the mirror housing assembly (2).
- Disconnect the two terminals from the mirror heater connector (if equipped).
Scheme 36
- Place mirror glass and holder and mirror housing assembly (actuator) in a horizontal position.
- Connect the two terminals to the mirror heater connector (if equipped).
- Engage the upper tabs on the mirror glass and holder (1) onto the mirror motor (2) Then press the lower side of mirror face until a click sound is heard to engage the lower tabs. NOTE: After installation, visually make sure lower two tabs are securely engaged from the bottom of mirror face. Make sure to insert the harness terminals into the correct connector. Do not confuse the locations.
Scheme 37
- Using a suitable tool disengage the upper mirror cover pawls.
- Using a suitable tool disengage the lower mirror cover pawls and remove mirror cover. CAUTION: Be careful not to damage the mirror or mirror cover with tool.
