REAR RH: Component Function Check Nissan Altima L32

Door System & Door Lock System (Except Hybrid) 8 illustrations ~1597 words

REAR RH: Component Function Check

  1. CHECK FUNCTION Use CONSULT-III to perform Active Test ("DOOR LOCK"). Touch "ALL LOCK" or "ALL UNLOCK" to check that it works normally. Is the inspection result normal? YES: Door lock actuator is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-272606-S16671728402007112300000) ".
  1. CHECK TRUNK LID OPENER CANCEL SWITCH Check trunk lid opener cancel switch position. Is trunk lid opener cancel switch turned OFF (CANCEL)? Yes: Turn on trunk lid opener cancel switch. No: GO TO 2.
  2. CHECK FUNCTION Perform Active Test TRUNK/GLASS HATCH with CONSULT-III. Touch "OPEN" and check that trunk lid opens. Is the inspection result normal? YES: Trunk lid opener actuator is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S27312903902007112300000) ".
  1. CHECK FUNCTION With CONSULT-III Check Intelligent Key warning buzzer OUTSIDE BUZZER in Active Test mode. Is the inspection result normal? YES: Intelligent Key warning buzzer (engine room) is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S10171610232007112300000) ".
  1. CHECK DOOR REQUEST SWITCH Check that door request switch operates normally. Is the inspection result normal? YES: GO TO 2. NO: Inspect door request switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-272606-S21580085312007112300000) ".
  2. CHECK FUNCTION Be sure that Intelligent Key is in each outside key antenna detection range. Does door lock/unlock when each request switch is pressed? YES: Outside key antenna is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S14222160912007112300000) ".

Scheme 65

Scheme 65: Diagnosis Procedure
Scheme 65: Diagnosis Procedure

Scheme 66

Scheme 66
Scheme 66
  1. CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 1 Turn ignition switch OFF. Check signal between BCM connector and ground with oscilloscope. CONNECTOR TERMINAL SIGNAL REFERENCE Terminals Condition Signal (Reference value.) (+) (-) BCM connector Terminal M19 Driver side 65 Ground Request switch is pushed When Intelligent Key is in the antenna detection area. Passenger side 63 M21 Rear bumper 119 When Intelligent Key is not in the antenna detection area. Is the inspection result normal? YES: GO TO 4 . NO: GO TO 2.
  2. CHECK OUTSIDE KEY ANTENNA CIRCUIT Disconnect BCM and front outside handle connector. Check continuity between BCM connector and outside key antenna connector. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Outside key antenna connector Terminal Continuity M19 65 D6 (driver side) 1 Yes 64 2 63 D106 (passenger side) 1 62 2 M21 119 B46 (rear bumper) 1 118 2 Check continuity between BCM connector and ground. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Ground Continuity M19 62 No 63 64 65 M21 118 119 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness between BCM and outside key antenna.
  3. CHECK OUTSIDE KEY ANTENNA INPUT SIGNAL 2 Replace outside key antenna. (New antenna or other antenna) Connect BCM and outside key antenna connector. Check signal between BCM connector and ground with oscilloscope. CONNECTOR TERMINAL SIGNAL REFERENCE Terminals Condition Signal (Reference value.) (+) (-) BCM connector Terminal M19 Driver side 65 Ground Door request switch is pushed When Intelligent Key is in the antenna detection area. Passenger side 63 M21 Rear bumper 119 When Intelligent Key is not in the antenna detection area. Is the inspection result normal? YES: Replace outside key antenna. NO: GO TO 4.
  4. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ". : INSPECTION END.
  1. CHECK FUNCTION With CONSULT-III Check remote keyless entry receiver RKE OPE COUN1 in Data Monitor mode with CONSULT-III. DATA MONITOR MODE CONDITION Monitor item Condition RKE OPE COUN1 Checks whether value changes when operating Intelligent Key.

Is the inspection result normal?

YES: Remote keyless entry receiver is OK.

NO: Refer to " DIAGNOSIS PROCEDURE ".

Scheme 67

Scheme 67: Diagnosis Procedure
Scheme 67: Diagnosis Procedure

Scheme 68

Scheme 68
Scheme 68
  1. CHECK REMOTE KEYLESS ENTRY RECEIVER OUTPUT SIGNAL Turn ignition switch OFF. Check signal between remote keyless entry receiver connector and ground with oscilloscope. CONNECTOR TERMINAL SIGNAL REFERENCE Terminals Condition Signal (Reference value) (+) (-) Remote keyless entry receiver connector Terminal M27 2 Ground Waiting (All doors closed) When signal is received (All doors closed) Is the inspection result normal? YES: GO TO 7 . NO: GO TO 2.
  2. CHECK REMOTE KEYLESS ENTRY RECEIVER POWER SUPPLY Disconnect remote keyless entry receiver connector. Check signal between remote keyless entry receiver connector and ground with oscilloscope. CONNECTOR TERMINAL SIGNAL REFERENCE Terminals Signal (Reference value) (+) (-) Remote keyless entry receiver connector Terminal M27 4 Ground Is the inspection result normal? YES: GO TO 4 . NO: GO TO 3.
  3. CHECK REMOTE KEYLESS ENTRY RECEIVER CIRCUIT 1 Disconnect BCM connector. Check continuity between BCM connector and remote keyless entry receiver connector. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Remote keyless entry receiver connector Terminal Continuity M19 91 M27 4 Yes Check continuity between BCM connector and ground. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Ground Continuity M19 91 No Is the inspection result normal? YES: Reconnect BCM, GO TO 4. NO: Repair or replace harness between BCM and remote keyless entry receiver.
  4. CHECK REMOTE KEYLESS ENTRY RECEIVER GROUND CIRCUIT Check continuity between remote keyless entry receiver connector and ground. CONNECTOR TERMINAL CONTINUITY REFERENCE Remote keyless entry receiver connector Terminal Ground Continuity M27 1 Yes Is the inspection result normal? YES: GO TO 6 . NO: GO TO 5.
  5. CHECK REMOTE KEYLESS ENTRY RECEIVER CIRCUIT 2 Check continuity between BCM connector and remote keyless entry receiver connector. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Remote keyless entry receiver connector Terminal Continuity M18 45 M27 1 Yes Is the inspection result normal? YES: GO TO 7 . NO: Repair or replace harness between BCM and remote keyless entry receiver.
  6. CHECK REMOTE KEYLESS ENTRY RECEIVER CIRCUIT 3 Check continuity between BCM connector and remote keyless entry receiver connector. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Remote keyless entry receiver connector Terminal Continuity M19 71 M27 2 Yes Check continuity between BCM connector and ground. CONNECTOR TERMINAL CONTINUITY REFERENCE BCM connector Terminal Ground Continuity M19 71 No Is the inspection result normal? YES: GO TO 7. NO: Repair or replace harness between BCM and remote keyless entry.
  7. CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-272588-S25405727752007112300000) ". : INSPECTION END.
  1. CHECK FUNCTION With CONSULT-III Check remote keyless entry receiver RKE OPE COUN1 in Data Monitor mode with CONSULT-III. DATA MONITOR MODE CONDITION Monitor item Condition RKE OPE COUN1 Check that the numerical value is changing while operating on the Intelligent Key. Is the inspection result normal? YES: Intelligent Key is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S27862502482007112300000) ".

Scheme 69

Scheme 69: Diagnosis Procedure
Scheme 69: Diagnosis Procedure

Scheme 70

Scheme 70
Scheme 70
  1. CHECK INTELLIGENT KEY BATTERY Check by connecting a resistance (approximately 300ohms) so that the current value becomes about 10 mA. Standard: Approx. 2.5-3.0V Is the measurement value within specification? YES: GO TO 2. NO: Replace Intelligent Key battery. (Scheme 54): Checking Connecting Resistance
  2. CHECK KEYFOB FUNCTION Check keyfob function using Remote Keyless Entry Tester J-43241. Does the test pass? YES: Keyfob is OK. NO: Replace keyfob. Refer to CONSULT-III operation manual. (Scheme 55): Identifying Remote Keyless Entry Tester J-43241

Scheme 71

Scheme 71: Component Inspection
Scheme 71: Component Inspection

Scheme 72

Scheme 72
Scheme 72
  1. Replace Intelligent KEY BATTERY Release the lock knob at the back of the Intelligent Key and remove the mechanical key. Insert a flat-blade screwdriver (A) wrapped with a cloth into the slit of the corner and twist it to separate the upper part from the lower part. CAUTION: Do not touch the circuit board or battery terminal. The keyfob is water-resistant. However, if it does get wet, immediately wipe it dry. (Scheme 56): Inserting Flat-Blade Screwdriver Into Slit Of Corner Replace the battery with new one. Align the tips of the upper and lower parts, and then push them together until it is securely closed. CAUTION: When replacing battery, keep dirt, grease, and other foreign materials off the electrode contact area. After replacing the battery, check that all Intelligent Key functions work normally. Is the inspection result normal? YES: Intelligent Key is OK. NO: Check remote keyless entry receiver. Refer to " «COMPONENT FUNCTION CHECK»(ref-272606-S36676020482007112300000) ". (Scheme 57): Aligning Tips Of Upper And Lower Parts

Refer to CONSULT-III operation manual.

  1. CHECK FUNCTION With CONSULT-III Check key slot illumination KEY SLOT ILLUMI in Active Test mode. Is the inspection result normal? YES: Key slot function is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S23344604892007112300000) ".
  1. CHECK FUNCTION Select HORN in "ACTIVE TEST" mode with CONSULT-III. Check the horn (high/low) operation. ACTIVE TEST Test item Description HORN ON Horn relay ON (for 20 ms) Is the operation normal? YES: INSPECTION END. NO: Go to " «DIAGNOSIS PROCEDURE»(ref-272606-S29250872172007112300000) ".
  1. CHECK FUNCTION With CONSULT-III Check the operation with ("LCD") in the Active Test. Is each warning displayed on meter display? Is the inspection result normal? YES: Meter display is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S03128341702007112300000) ".
  1. CHECK FUNCTION With CONSULT-III Check the operation with "INSIDE BUZZER" in the Active Test. Touch "TAKE OUT", "KNOB" or "KEY" on screen. Is the inspection result normal? Yes: Warning buzzer into combination meter is OK. No: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S40150905992007112300000) ".
  1. CHECK FUNCTION Check hazard warning lamp ("FLASHER") in Active Test. Is the inspection result normal? YES: Hazard warning lamp circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S17559436162007112300000) ".
  1. CHECK FUNCTION Check that system receiver (garage door opener, etc.) operates with original hand-held transmitter. Is the inspection result normal? YES: GO TO 2. NO: Receiver or hand-held transmitter is malfunctioning.
  2. CHECK ILLUMINATE Turn ignition switch "OFF". Press each of the transmitter buttons and watch for the red light to illuminate with each button. Is the inspection result normal? YES: GO TO 3. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-272606-S08926574502007112300000) ".
  3. CHECK TRANSMITTER Check transmitter with Tool*. *:For details, refer to Technical Service Bulletin. Is the inspection result normal? YES: Receiver or hand-held transmitter malfunction, not vehicle related. NO: Replace auto anti-dazzling inside mirror (Homelink universal transceiver). Refer to " «REMOVAL AND INSTALLATION»(ref-272643-S21915896912007112300000) ".
