CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT-III does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
CAN System Type Specification Chart (Style A). Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
CAN System Type Specification Chart (Style B). Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart.
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE "for how to use CAN system specification chart.
| Body type | Sedan | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | |||||||||||||
| Engine | QR25DE | VQ35DE | ||||||||||||
| Transmission | M/T | CVT | M/T | CVT | ||||||||||
| Brake control | ABS | ABS | TCS | VDC | TCS | VDC | ||||||||
| Navigation system | X | X | X | X | X | X | ||||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 |
| Start CAN Diagnosis (CONSULT-III) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 |
| X: Applicable | ||||||||||||||
CAN SYSTEM SPECIFICATION CHART
