Parts Requiring Angular Tightening
- Use an angle wrench for the final tightening of the following engine parts.
- Cylinder head bolts
- Lower cylinder block bolts
- Connecting rod cap bolts
- Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angular tightening)
- Do not use a torque value for final tightening.
- The torque value for these parts are for a preliminary step.
- Ensure thread and seat surfaces are clean and coated with engine oil.
Scheme 1
- After removing the bolts and nuts, separate the mating surface and remove the sealant using Tool. Tool number : KV10111100 (J-37228) CAUTION: Be careful not to damage the mating surfaces.
- In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the RTV Silicone Sealant is applied. Use a plastic hammer to slide the cutter (2) by tapping on the side. CAUTION: If for some unavoidable reason a tool such as a flat-bladed screwdriver is used, be careful not to damage the mating surfaces.
GENERAL SPECIFICATIONS
Identifying General Specifications Cylinder arrangement In-line 4 Displacement cm 3 (in 3 ) 2,488 (151.82) Bore and stroke mm (in) 89.0 x 100 (3.50 x 3.94) Valve arrangement DOHC Firing order 1-3-4-2 Number of piston rings Compression 2 Oil 1 Compression ratio 9.5:1 Compression pressure kPa (kg/cm 2 , psi) / 250 rpm Standard 1,250 (12.8, 181.3) Minimum 1,060 (10.8, 153.7) Differential limit between cylinders 100 (1.0, 14) Valve timing Unit: degree a b c d e f 224° 244° 0° 64° 3° 41°
Scheme 2
