CONSULT-II Function

Refer to " CONSULT-II FUNCTION (BCM) " in HEADLAMP (FOR USA).

Refer to " CONSULT-II FUNCTION (IPDM E/R) " in HEADLAMP (FOR USA).

Scheme 171

Scheme 171: Front Fog Lamps Do Not Illuminate (Both Sides)
Scheme 171: Front Fog Lamps Do Not Illuminate (Both Sides)

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175
  1. FOG LAMP ACTIVE TEST Select "IPDM E/R" on CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen. Select "LAMP" on "SELECT TEST ITEM" screen. Touch "FOG" on "ACTIVE TEST" screen. Make sure fog lamps operate. Fog lamps should operate. OK or NG OK: GO TO 2. NG: GO TO 4 .
  2. INSPECTION 1 BETWEEN COMBINATION SWITCH AND BCM Select "BCM" on CONSULT-II. Carry out BCM self-diagnosis. Displayed results of self-diagnosis NO MALFUNCTION DETECTED: GO TO 3. CAN COMMUNICATION OR CAN SYSTEM: Inspect the BCM CAN communications system. Refer to " «CAN COMMUNICATION»(ref-232740-S30757672302006051900000) ". OPEN DETECT 1 - 5: Inspect combination switch system. Refer to " «COMBINATION SWITCH INSPECTION»(ref-232748-S42877991142006052000000) ".
  3. INSPECTION 2 BETWEEN COMBINATION SWITCH AND BCM Select "BCM" on CONSULT-II. With "HEAD LAMP" data monitor, make sure "FR FOG SW" turns ON-OFF linked with operation of lighting switch. When lighting switch is in FOG position: FR FOG SW ON OK or NG OK: Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-232757-S32954183312006051900000) ". NG: Replace lighting switch. Refer to " «REMOVAL AND INSTALLATION»(ref-232748-S21936747122006052000000) ".
  4. IPDM E/R INSPECTION Start active test. Refer to " «AUTO ACTIVE TEST»(ref-232731-S35696712802006051900000) ". When front fog lamp relay is operating, check voltage between left/right front fog lamp connector terminals and ground. OK or NG OK: Check front fog lamp bulbs and replace as necessary. NG: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-232731-S13506618902006051900000) ".

Scheme 176

Scheme 176: Front Fog Lamp Does Not Illuminate (One Side)
Scheme 176: Front Fog Lamp Does Not Illuminate (One Side)

Scheme 177

Scheme 177
Scheme 177
  1. BULB INSPECTION Inspect bulb of lamp which does not illuminate. OK or NG OK: GO TO 2. NG: Replace lamp bulb. Refer to " «BULB REPLACEMENT»(ref-232748-S39882519622006052000000) ".
  2. INSPECTION BETWEEN IPDM E/R AND FRONT FOG LAMPS Disconnect IPDM E/R connector and inoperative front fog lamp connector. Check continuity between harness connector terminals of IPDM E/R and harness connector terminal of front fog lamps. OK or NG OK: Check ground circuit. If OK, replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-232731-S13506618902006051900000) ". If NG, repair harness or connector. NG: Check for short circuits and open circuits in harness between IPDM E/R and front fog lamps.
