Piston Selection Table
| Unit: mm (in) | ||
|---|---|---|
| Grade number (Mark) | 2 (or no mark) | 3 |
| Inner diameter of cylinder bore | 88.010 - 89.020 (3.5043 - 3.5047) | 89.020 -89.030 (3.5047 - 3.5051) |
| Outer diameter of piston | 88.990 - 89.000 (3.5035 - 3.5039) | 89.000 -89.010 (3.5039 - 3.5043) |
PISTON SELECTION TABLE
Note. The piston is available together with piston pin as an assembly. The piston pin (piston pin bore) grade is provided only for the parts installed at the plant. For service parts, no grades can be selected. Only 0 grade is available.
Scheme 192
Scheme 193
- Apply big end inside diameter grade stamped on connecting rod side face to the row in the " «CONNECTING ROD BEARING SELECTION TABLE»(ref-232721-S24173353462006052000000) ".
- Apply pin diameter grade stamped on crankshaft front side to the column in the " «CONNECTING ROD BEARING SELECTION TABLE»(ref-232721-S24173353462006052000000) ".
- Read the symbol at the cross point of selected row and column in the " «CONNECTING ROD BEARING SELECTION TABLE»(ref-232721-S24173353462006052000000) ".
- Apply the symbol obtained to connecting rod bearing grade table to select.
Scheme 194
- Measure dimensions of the big end inner diameter of connecting rod and outer diameter of crankshaft pin individually.
- Apply the dimension measured to the " «CONNECTING ROD BEARING SELECTION TABLE»(ref-232721-S24173353462006052000000) " below.
| Grade | 0 | 1 | 2 | 3 |
|---|---|---|---|---|
| Upper / Lower thickness mm (in.) | 1.499/ 1.495 (0.0590 / 0.0589) | 1.503 / 1.499 (0.0592 / 0.0590) | 1.507 / 1.503 (0.0593 / 0.0592) | 1.511 / 1.507 (0.0595 / 0.0593) |
| Identification color | Black | Brown | Green | Yellow |
CONNECTING ROD BEARING SELECTION TABLE
