TRANSAXLE
Transaxle General Specifications Chart Engine QR25DE VQ35DE Transaxle model RS5F51A Model code number 8J206 8J204 Number of speed 5 Synchromesh type Warner Shift pattern Gear ratio 1st 3.416 3.153 2nd 1.944 1.842 3rd 1.258 4th 0.947 5th 0.772 Reverse 3.252 3.002 Number of teeth Input gear 1st 12 13 2nd 18 19 3rd 31 4th 38 5th 44 Reverse 12 13 Main gear 1st 49 2nd 35 3rd 39 4th 36 5th 34 Reverse 38 Reverse idler gear Front 37 Rear 38 Oil capacity l (lmp pt) 2.3 (4) Remarks Reverse synchronizer Installed Double baulk ring type synchronizer 1st & 2rd synchronizer
Scheme 180
Scheme 181
Scheme 181: Gear End Play
Scheme 182
Scheme 182: 3RD, 4TH, 5TH & REVERSE BAULK RING
Scheme 183
Scheme 183: 1ST AND 2ND DOUBLE BAULK RING
Scheme 184
Scheme 184: INPUT SHAFT SPACER
Scheme 185
Scheme 185: 5TH MAIN GEAR
Scheme 186
Scheme 186: MAINSHAFT C-RING
Scheme 187
Scheme 187: INPUT SHAFT THRUST WASHER
Scheme 188
Scheme 188: DIFFERENTIAL SIDE GEAR THRUST WASHER
Scheme 189
Scheme 189: MAINSHAFT ADJUSTING SHIM
Scheme 190
Scheme 190: INPUT SHAFT REAR BEARING ADJUSTING SHIM
Scheme 191
Scheme 191: MAINSHAFT REAR BEARING ADJUSTING SHIM
Scheme 192
Scheme 192: REVERSE IDLER GEAR ADJUSTING SHIMS
Scheme 193
Scheme 193: BEARING PRELOAD
Scheme 194
Scheme 194: DIFFERENTIAL SIDE BEARING ADJUSTING SHIMS
