Automatic Headlight Systems: Other Nissan Altima L31

Headlights 3 illustrations ~374 words

BATTERY SAVER CONTROL

When the combination switch (lighting switch) is in the "AUTO" position, and the ignition switch is turned from "ON" or "ACC" to "OFF", and one of the doors is opened, the battery saver feature is activated.

Under this condition, the headlights remain illuminated for 5 minutes, unless the combination switch (lighting switch) position is changed. If the combination switch (lighting switch) position is changed, then the headlights are turned "OFF".

SHUT OFF DELAY

When the ignition switch is turned from "ON" to "OFF" while the auto light system is activated and the headlights are illuminated, the shut off delay feature is activated. Under this condition, the BCM no longer receives a voltage signal at terminal No. 35, and this starts the auto light shut off delay timer. The shut off delay timer is active until one of the doors is opened, or the combination switch (lighting switch) position is changed. If one of the doors is opened, the shut off delay feature is deactivated, and the battery saver control feature is activated. If the combination switch (lighting switch) position is changed, the headlights are turned off.

MAJOR COMPONENTS & FUNCTIONS

For major components and functions (Scheme 16)

Scheme 16

Scheme 16: MAJOR COMPONENTS & FUNCTIONS

Setting Change Functions

Sensitivity of automatic light system can be adjusted using CONSULT-II. See WORK SUPPORT .

CONSULT-II FUNCTION

CONSULT-II has a display function for work support, self-diagnosis, data monitor and active test for each part by combining data receiving and sending via the communication line from BCM. (Scheme 17)

Scheme 17

Scheme 17: CONSULT-II FUNCTION

Consult-II Basic Operation

  1. With the ignition switch "OFF", connect CONSULT-II to the vehicle data link connector, then turn ignition switch "ON".
  2. Touch "START".
  3. Touch "BCM" on "SELECT SYSTEM" screen.
  4. Select the desired part to be diagnosed on the "SELECT TEST ITEM" screen.

DATA MONITOR

Operation Procedure

  1. Touch "HEADLIGHT" on "SELECT TEST ITEM" screen.
  2. Touch "DATA MONITOR" on "SELECT DIAG MODE" screen.
  3. Touch either "ALL SIGNALS" or "SELECTION FROM MENU".
  4. Touch "START".
  5. When "SELECTION FROM MENU" is selected, touch items to be monitored. When "ALL SIGNALS" is selected, all the signals will be monitored. (Scheme 18)
  6. Touch "RECORD" while monitoring, then the status of the monitored item can be recorded. To stop recording, touch "STOP".

Scheme 18
