CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN "H" line, CAN "L" line) allowing a high rate of information transmission with less wiring. (Scheme 1)- (Scheme 3). Each control unit transmits/receives data but selectively reads required data only. (Scheme 4)- (Scheme 6).
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
