Charging System & Starter: Removal & Installation Nissan Altima L31

Installation

To install, reverse the removal procedure.

Scheme 48

To install, reverse the removal procedure.

Scheme 49

Removal

1. Disconnect the negative battery terminal.
2. Remove radiator, refer to «RADIATOR»(ref-183495-S00177931992005081400000)
3. Remove front/right-side engine under cover
4. Remove the drive belt, refer to «DRIVE BELTS 2.5L»(ref-159291-S07922387492005042600000) or «DRIVE BELTS 3.5L»(ref-163530-S11733559692005050200000) .
5. Remove idler pulley.
6. Remove the generator adjustable top mount, using power tools.
7. Remove the generator lower mount bolt and nuts, using power tools.
8. Remove the generator lower front bracket bolt, using power tools.
9. Disconnect the generator harness connectors.
10. Slide the generator out and remove.

To install, reverse the removal procedure.

Scheme 50

Scheme 51

Scheme 52

Scheme 53
