TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Altima |
| Generator Adjusting Bolt | 12-15 (16-21) |
| Generator Pivot Bolt | 12-15 (16-21) |
| Generator Pulley Nut | 36-47 (49-64) |
| Frontier & Xterra |
| 2.4L |
| Generator Adjusting Bolt | 12-14 (16-19) |
| Generator Pivot Bolt | 32-38 (44-52) |
| Generator Pulley Nut | 36-47 (49-64) |
| 3.3L |
| Generator Adjusting Bolt | 12-14 (16-19) |
| Generator Pivot Bolt | 16-22 (22-29) |
| Generator Pulley Nut | 36-47 (49-64) |
| Maxima |
| Generator Adjusting Bolt | 12-15 (16-21) |
| Generator Pivot Bolt | 32-38 (44-52) |
| Generator Pulley Nut | 47-61 (64-83) |
| Pathfinder |
| Generator Adjusting Bolt | 32-43 (43-58) |
| Generator Pivot Bolt | 32-43 (43-58) |
| Generator Pulley Nut | 29-43 (39-59) |
| Sentra |
| 1.8L |
| Generator Adjusting Bolt | 13-17 (17-24) |
| Generator Pivot Bolt | 25-34 (33-46) |
| Generator Pulley Nut | 36-47 (49-64) |
| 2.0L |
| Generator Adjusting Bolt | 18-23 (25-31) |
| Generator Pivot Bolt | 25-34 (33-46) |
| Generator Pulley Nut | 36-47 (49-64) |
Charging System Wiring Diagram (Altima). Scheme 1
Scheme 1: Charging System Wiring Diagram (Altima)
Charging System Wiring Diagram (Frontier 2-Door With 2.4L Engine). Scheme 2
Scheme 2: Charging System Wiring Diagram (Frontier 2-Door With 2.4L Engine)
Charging System Wiring Diagram (Frontier 2-Door With 3.3L Engine). Scheme 3
Scheme 3: Charging System Wiring Diagram (Frontier 2-Door With 3.3L Engine)
Charging System Wiring Diagram (Frontier & Xterra With 2.4L Engine). Scheme 4
Scheme 4: Charging System Wiring Diagram (Frontier & Xterra With 2.4L Engine)
Charging System Wiring Diagram (Frontier & Xterra With 3.3L Engine). Scheme 5
Scheme 5: Charging System Wiring Diagram (Frontier & Xterra With 3.3L Engine)
Charging System Wiring Diagram (Maxima). Scheme 6
Scheme 6: Charging System Wiring Diagram (Maxima)
Charging System Wiring Diagram (Pathfinder). Scheme 7
Scheme 7: Charging System Wiring Diagram (Pathfinder)
Charging System Wiring Diagram (Sentra). Scheme 8
Scheme 8: Charging System Wiring Diagram (Sentra)
