PHYSICAL VALUES
TERMINALS REFERENCE Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (BR) Ground Sensor power supply (Roof striker sensor LH) Output [Engine is running] 12 V 3 (DG) Ground Roof striker sensor RH Input [Engine is running] Roof lock assembly Hooked 0.8 V Released 3.0 V 4 (W) Ground Roof striker sensor LH Input [Engine is running] Roof lock assembly Hooked 0.8 V Released 3.0 V 8 (Y) Ground Back up lamp signal Input [Ignition switch: ON] Shift position R position Battery voltage Other than above 0 V 9 (SB) Ground Power source (Power window) Input [Ignition switch: OFF] Battery voltage 10 (O) Ground Trunk lid open request signal (BCM) Input [Ignition switch: ON] Trunk opener Operate 0 V --> Battery voltage --> 0 V Other than above 0 V 11 (O) Ground Roof status signal (Indicator lamp) Output [Engine is running] Soft top indicator lamp Illuminate 0 V Not illuminate Battery voltage 12 (SB) Ground Roof status signal (Audio) Output [Engine is running] Soft top system Fully open 9.5 V Other than above 0 V 14 (L) Ground Roof open/close switch (Close) Input [Engine is running] Close switch Pressed 0 V Released Battery voltage 15 (LG) Ground Roof open/close switch (Open) Input [Engine is running] Open switch Pressed 0 V Released Battery voltage 16 (V) Ground Trunk room lamp switch Input [Ignition switch: ON] Trunk lid Open 0 V Other than above Battery voltage 17 (BG) Ground CAN-H Input/Output - - 18 (P) Ground CAN-L Input/Output - - 19 (LG) Ground Local communication (Power window) Input/Output - 20 (V) Ground Local communication (BCM) Input/Output - 21 (BR) Ground Sensor power supply (Roof striker sensor RH) Output [Engine is running] 12 V 29 (DG) Ground Ground - - - 35 (P) Ground Ground (Roof open/close switch) - - - 41 (DG) Ground Trunk lid opener actuator Output Trunk lid opener Operate 0 V --> Battery voltage --> 0 V Stop 0 V 48 (R) Ground Power source (Rear window defogger) Input [Engine is running] Rear window defogger Active Battery voltage Not active 0 V 49 (R) Ground Power source (Rear window defogger) Input [Engine is running] Rear window defogger Active Battery voltage Not active 0 V 53 (R) Ground Power source (Roof) Input [Engine is running] Battery voltage 54 (B) Ground Ground (Roof) - - - 56 (W) Ground 5th bow latch close sensor Input [Engine is running] 5th bow latch Lock 0.8 V Other than above 3.0 V 57 (G) Ground 5th bow latch open sensor Input [Engine is running] 5th bow latch Unlock 0.8 V Other than above 3.0 V 58 (LG) Ground Storage lid status sensor RH (Open) Input [Engine is running] Storage lid Full open 0.8 V Other than above 3.0 V 59 (W) Ground Storage lid status sensor RH (Close) Input [Engine is running] Storage lid Full close 0.8 V Other than above 3.0 V 60 (DG) Ground Storage lid status sensor LH (Open) Input [Engine is running] Storage lid Full open 0.8 V Other than above 3.0 V 61 (Y) Ground Roof status sensor RH (Close) Input [Engine is running] Soft top Raised 0.8 V Other than above 3.0 V 66 (L) Ground Roof status sensor LH (Open) Input [Engine is running] Soft top Lowered 0.8 V Other than above 3.0 V 68 (P) Ground 5th bow status sensor RH Input [Engine is running] 5th bow Raised 0.8 V Other than above 3.0 V 69 (V) Ground Roof status sensor LH (Close) Input [Engine is running] Soft top Raised 0.8 V Other than above 3.0 V 70 (O) Ground 5th bow status sensor LH Input [Engine is running] 5th bow Lowered 0.8 V Other than above 3.0 V 71 (SB) Ground Roof latch lock sensor Input [Engine is running] Roof lock assembly Lock 0.8 V Other than above 3.0 V 72 (W/R) Ground Hydraulic pump temperature sensor Input [Engine is running] 0 - 4.8 V Output voltage varies with hydraulic pump temperature. 73 (R) Ground Hydraulic pump relay 2 ON signal Input [Engine is running] Hydraulic pump motor (Right rotation) Active 12 V Inactive 0 V 74 (R/B) Ground Hydraulic pump relay 1 ON signal Input [Engine is running] Hydraulic pump motor (Left rotation) Active 12 V Inactive 0 V 75 (BR) Ground Sensor power supply (Roof status sensor LH//5th bow latch open sensor/5th bow latch close sensor/5th bow striker sensor) Output [Engine is running] 12 V 76 (L) Ground 5th bow striker sensor Input [Engine is running] 5th bow striker Hooked 0.8 V Released 3.0 V 92 (BG) Ground Sensor ground (Hydraulic pump temperature sensor) - - - 93 (BR) Ground Sensor power supply (Roof status sensor RH/Storage lid status sensor RH) Output [Engine is running] 12 V 94 (BR) Ground Sensor power supply (Roof latch lock sensor/5th bow status sensor LH) Output [Engine is running] 12 V 95 (BR) Ground Sensor power supply (Storage lid status sensor/5th bow status sensor RH) Output [Engine is running] 12 V 96 (W) Ground Switching valve 4 Output [Engine is running] Switching valve 4 Active 12 V Inactive 0 V 97 (LG) Ground Switching valve 3 Output [Engine is running] Switching valve 3 Active 12 V Inactive 0 V 98 (L) Ground Switching valve 2 Output [Engine is running] Switching valve 2 Active 12 V Inactive 0 V 99 (O) Ground Switching valve 1 Output [Engine is running] Switching valve 1 Active 12 V Inactive 0 V 100 (BR) Ground Hydraulic pump relay 2 Output [Engine is running] Hydraulic pump motor (Right rotation) Active 12 V Inactive 0 V 101 (SB) Ground Hydraulic pump relay 1 Output [Engine is running] Hydraulic pump motor (Left rotation) Active 12 V Inactive 0 V 102 (P) Ground Switching valve 5 Output [Engine is running] Switching valve 5 Active 12 V Inactive 0 V 103 (B) Ground Hydraulic unit ground - - - 104 (R) Ground Rear window defogger power supply Output [Engine is running] Rear window defogger NOTE: Roof is fully closed. Active Battery voltage Not active 0 V 111 (R) Ground Rear window defogger power supply Output [Engine is running] Rear window defogger NOTE: Roof is fully closed. Active Battery voltage Not active 0 V
