Engine Mechanical: Specifications Nissan 370Z I

FOR USA AND CANADA : Parts Requiring Angle Tightening

1. Use the angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Lower cylinder block bolts Connecting rod cap bolts
2. Do not use a torque value for final tightening.
3. The torque value for these parts are for a preliminary step.
4. Ensure thread and seat surfaces are clean and coated with engine oil.

FOR MEXICO : Parts Requiring Angle Tightening

1. Use the angle wrench [SST: KV10112100 (BT8653-A)] for the final tightening of the following engine parts: Cylinder head bolts Lower cylinder block bolts Connecting rod cap bolts
2. Do not use a torque value for final tightening.
3. The torque value for these parts are for a preliminary step.
4. Ensure thread and seat surfaces are clean and coated with engine oil.

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS Cylinder arrangement V-6 Displacement cm 3 (cu in) 3, 696 (225.53) Bore and stroke mm (in) 95.5 x 86.0 (3.760 x 3.386) Valve arrangement DOHC Firing order 1-2-3-4-5-6 Number of piston rings Compression 2 Oil 1 Number of main bearings 4 Compression ratio 11 Compression pressure kPa (kg/cm 2 , psi)/200 RPM Standard 1, 667 - 2, 354 (17 - 24, 242 - 341) Minimum 1, 226 (12.5, 178) Differential limit between cylinders 98 (1.0, 14) Cylinder number

Scheme 1

VALVE SPECIFICATION
